Hardi SMARTCOM ISOBUS UT SW A.2.2 Series User Manual

7 - Fault Finding
120
Power Distribution Unit PDU 3
Location: Centre Section
Sprayer:
NAVIGATOR DELTA FORCE
MEGA Z-version
26070300 F1 AUX 1 X1004
F2 AUX 2 X1007
F3 Guest 1 X400
F4 AUX SW 1 X1001
F5 AUX SW 2 X1003
F6 Guest 2 X500
- F7 25 A 261605 ECU-IO 1 X700
- F8 25 A 261605 ECU Master X600
- F9 25 A 261605 ECU-IO 2 X800
Power Distribution Unit PDU 3
Location: Centre Section
Sprayer:
NAVIGATOR DELTA FORCE with
AutoSlant/AutoTerrain
MEGA Z-version with AutoSlant
26070300 F1 AUX 1 X1004
- F2 15 A 28048600 AUX 2 X1007
- F3 10 A 28048500 Guest 1 X400
F4 AUX SW 1 X1001
F5 AUX SW 2 X1003
F6 Guest 2 X500
- F7 25 A 261605 ECU-IO 1 X700
- F8 25 A 261605 ECU Master X600
- F9 25 A 261605 ECU-IO 2 X800
Power Distribution Unit PDU 3
Location: Centre Section
Sprayer:
NAVIGATOR DELTA FORCE with
PrimeFlow and
AutoSlant/AutoTerrain
26070300 - F1 10 A 28048500 AUX 1 X1004
- F2 15 A 28048600 AUX 2 X1007
- F3 10 A 28048500 Guest 1 X400
F4 AUX SW 1 X1001
F5 AUX SW 2 X1003
F6 Guest 2 X500
- F7 25 A 261605 ECU-IO 1 X700
- F8 25 A 261605 ECU Master X600
- F9 25 A 261605 ECU-IO 2 X800
Power Distribution Unit PDU 3
Location: Centre Section
Sprayer:
PrimeFlow equipped
26070300 - F1 10 A 28048500 AUX 1 X1004
F2 AUX 2 X1007
F3 Guest 1 X400
F4 AUX SW 1 X1001
F5 AUX SW 2 X1003
F6 Guest 2 X500
- F7 25 A 261605 ECU-IO 1 X700
- F8 25 A 261605 ECU Master X600
- F9 25 A 261605 ECU-IO 2 X800
Printed Circuit Board PDU Board Item
Number
Assigned Sprayer
Function
Fuse Socket Fuse Rating Fuse Item
Number
PCB
Function
Connector
