8 - Technical Specifications
Specifications
Electronic Control Units
Dimension Approx. 270 x 190 x 70 mm
Operational Voltage Range 9 V - 16 V
Current Consumption Up to 20 A / short term 30 A
Standby Current Consumption < 10mA
Base Board 6x Independent Sensor Supply Voltage 50 mA
2x Analogue Voltage or Current Sensors 0V-5V/0mA-24 mA
4x Analogue Voltage or Frequency Sensors 0V-5V/12V5kHz
Expansions 2x Extension Boards available at the moment 1x Output Extension Board PB0S16A
1x Sensor Extension Board PB8S4A
Groups for Actuators Outputs for the Actuators can be connected in groups BA6S15A: up to 15 Actuators
PB0S16A: up to 16 Actuators
Connector Molex CMC Connector
Main Board
1x 32 Pins: Supply & Communication
1x 48 Pins: Outputs & Sensors
Expansion 1x 32 Pins: Optional Extensions
Environmental Operating Temperature -20°C - 70°C
IP protection class IP67 / IP69K
Standards Agricultural Standard ISO 15003
ISOBUS Standard ISO 11783
Functional Safety Standard ISO 13849
