3 - Description
19
FluidBox
The FluidBox is only present for i-sprayers, and is used in conjunction
with AutoAgitation, AutoFill and AutoWash functions. It is a remote
control of the liquid system and is logically placed at the filling area
(storage locker).
• All stationary spraying operations can be performed without
entering the tractor cabin.
Emergency STOP of all functions.
Status LED.
ON = Ready and communicating.
OFF or flashing = No communication with SmartCom.
Main ON/OFF.
Turns spraying ON/OFF. Manual spray pressure increase/decrease.
AutoFill start.
Opens the FastFiller valve.
AutoFill manual open and AutoFill stop.
Controls the FastFiller valve. Pressing the stop-button will abort the filling
process.
AutoAgitation set controls.
Pre-sets for agitation amounts.
Suction SmartValve set control.
Selects source for suction to pump.
Pressure SmartValve set control.
Selects destination for liquid from pump.
