〈Transistor〉
ＲＴ１Ｎ１４４Ｘ SERIES
Transistor With Resistor
For Switching Application
Silicon NPN Epitaxial Type
ISAHAY
A
ELECTRONIC
S
CORPORATION
COLLECTOR OUTPUT CAPACITANCE VS.
COLLECTOR TO BASE VOLTAGE
0
1
2
3
4
5
0.1 1 10 100
COLLECTOR TO BASE VOLTAGE VCB(V)
IE=0A
Ta=25℃
COLLECTOR OUTPUT CAPACITANCE Cob(pF)
INPUT ON VOLTAGE
VS COLLECTOR CURRENT
0.1
1
10
0.1 1 10 100
COLLECTOR CURRENT IC(mA)
INPUT ON VOLTAGE VI(ON)(V
)
VCE=200mV
Ta=25℃
Ta=100℃
Ta=-40℃
COMMON EMITTER OUTPUT
0
5
10
15
20
25
30
0123456
COLLECTOR TO EMITTER VOLTAGE VCE(V)
COLLECTOR CURRENT IC(mA)
Ta=25℃
IB=0.03mA
IB=0.04mA
IB=0.05mA
IB=0.06mA
IB=0.07mA
IB=0.08mA
IB=0.09mA
IB=0.10mA
IB=0.02mA
DC FORWARD CURRENT GAIN
VS COLLECTOR CURRENT
1
10
100
1000
0.1 1 10 100
COLLECTOR CURRENT IC(mA)
DC FORWARD CURRENT GAIN hFE
VCE=5V
Ta=25℃
Ta=100℃
Ta=-40℃
COLLECTOR CURRENT
VS INPUT OFF VOLTAGE
1
10
100
1000
00.511.52
INPUT OFF VOLTAGE VI(OFF)(V)
COLLECTOR CURRENT IC(uA)
VCE=5V
Ta=25℃
Ta=100℃
Ta=-40℃
COLLECTOR TO EMITTER SATURATION
VOLTAGE VS. COLLECTOR CURRENT
10
100
1000
1 10 100
COLLECTOR CURRENT IC(mA)
IC/IB=20/1
Ta=25℃
Ta=100℃
Ta=-40℃
COLLECTOR TO EMITTER STURATION
VOLTAGEVCE(sat)(mV)
