600mA LOW DROPOUT LINEAR REGULATOR AP2317 600mA LOW DROPOUT LINEAR REGULATOR AP1117M
Data Sheet
LOW DROPOUT LINEAR REGULATOR AZ1117C
2
Jan. 2012 Rev. 1. 5 BCD Semiconductor Manufacturing Limited
H Package
(SOT-223)
Pin Configuration
VOUT
IN PUT
OUTPUT
ADJ/GND
1
2
3
Figure 2. Pin Configuration of AZ1117C (Top View)
D Package
(TO-252-2 (1))
1
2
3
1
2
3
INPUT
OUTPUT
ADJ/GND
INPUT
OUTPUT
ADJ/GND
INPUT
OUTPUT
ADJ/GND
(TO-252-2 (2))
(TO-252-2 (3))
1
2
3
R Package
(SOT-89)
1
2
3
INP UT
OUTPUT
ADJ/GND
VOUT
(TO-252-2 (4))
INPUT
OUTPUT
ADJ/GND
VOUT
1
2
3
