AVR645 Electrical Parts List
Ref. Designator Part Number
Description
DSP PCB ASS'Y
Capacitors
C119 H03-CEZXA0479MN-R CM 47MI0F +80%-20% 5.5V 70C SCDA5R5473V
C27 CCKID0470NA-R CC 47PF +10% -10% 50.0V Y5P
C26 CCKID0221NA-R CAPACITOR CERAMIC AXIAL 220PF 50V K Y5P
C801 C802 C803 CFIOC0104NN-R CPM 100N0F +10% 250.0V
C730 H03-CEHEC02275E-R CE 220UF +20% 10.0V P=5MM 85C SK 220/10V 5 X11
C204 H03-CEHEC0477MN-R CE 470U0F +20% 10.0V 85C P=5MM SK 470/10V 6.3 X11
C14 C105 C107 C114 C115
C118 C306 C309 C523 C524
C553 C554 C569 C570 C599
C601 C616 C617 C631 C632
C652 C657 C669 C680 C691
C692 C716 C724
H03-CEHFC01062S-R CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C45 C201 C206 C207 C208
C301 C302 C303 C305 C307
C308 C310 C311 C312 C314
C316 C505 C506 C525 C699
C702 C725 C738 C740 C741
C806
H03-CEHFC01072S-R CE 100UF +20% 16V D6.3XL7 P2.5MM 2000hours 85C
C104 C202 C304 C513 C514
C541 C544 C573 C576 C604
C605 C633 C636
H03-CEHFC04762S-R CE 47UF +20% 16V D5XL7 P2.5MM 2000hours 85C
C705 C707 C732 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C108 CEHIC04755E-R CE 4U7F +20% 50.0V 85C P5MM
C10 H03-CEHDC0108NN-R CE 1000UF +20% 6.3V 8X11.5 85C P5MM
C722 C715 H03-CEMHC0227AH-R CAP ELEC 220UF 35V M 8X11.5 SHL SAMYOUNG
C38 C75 C110 C117 C205 H03-CEMGC04762R-R CAP ELEC 47UF 25V M 6.3X5 SRE P2.5MM
C143 C358 C359 C731 C733 CZIKI0104CC-R CAP CHIP 100nF 100V X7R 10% 0805
C76 C135 C136 C140 C141
C172 C173 C174 C175 C176
C216 C331 C501 C502 C503
C504 C511 C512 C516 C517
C531 C532 C533 C534 C542
C543 C546 C547 C561 C562
C563 C564 C574 C575 C581
C582 C591 C592 C593 C594
C606 C607 C612 C613 C637
C638 C643 C644
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
OC10 OC11 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603 EU
C385 CZJII0101CE-R CAP CERAMIC/CHIP 100PF 50V CH J NPO 0805
C386 CZJII0102CC-R CAP CHIP 1nF 50V X7R J 0805
C322 C325 C328 C416 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C33 C34 C150 C151 C223
C224 C364 C371 C372
CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C139 C142 C373 C374 CZJII0470BE-R CAP CHIP 47P0F +5% -5% 50.0V NPO 0603
C714 C721 CZJII0471BE-R CCCFMIC 470P0F +5% -5% 50.0V NP0
C137 C138 C350 C645 C646 CZKII0102BC-R CAP CHIP 1N0F +10% -10% 50.0V X7R 0603
C7 C77 C323 C326 C329 C343
C346 C349 C351 C353 C361
C367 C370 C414
CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C398 CZKII0122BC-R CAP CHIP 1N2F +10% -10% 50.0V X7R 0603
C686 C712 C720 CZKII0272BC-R CAP CHIP 2N7F +10% -10% 50.0V X7R 0603
C688 CZKII0821BC-R CAP CHIP 820P0F +10% -10% 50.0V X7R 0603
