Harman Kardon AVR 645 Service Manual

AVR645 US/EU EXPLODED VIEW PARTS LIST
DESCRIPTION
# 645 US 645EU
QTY
1 H03-ZMC11S00200 AL DOOR AVR 1
2 H03-ZMD2702GAGY AL PANEL FRONT AVR 1
3 H03-ZMD2703GAGY BADGE FRONT AL AVR GREY HOT STAMPING 1
4 H03-ZMD27S20A00 BADGE harman/kardon COVER TOP AVR 1
5 H03-ZMD27S08A00 COVER TOP AVR 1
6 H03-ZVC11DWT200 TAPE PANEL 1
7 H03-ZVC11DWT100 TAPE DOOR 1
8 H03-ZMD12S01A00 SHIELD IR 1
9 H03-SOSS9CKX3NN
JACK PHONE 6.35 H70980110S 9P BK
1
10 H03-ZMB01S00100 BKT HEADPHONE 1
11 H03-SWA2B21PDA& SW PUSH POWER SDDLB15700 1
12 ZPC1006GAWH BUTTON STANDBY 1
13 ZPC1003GAGY BUTTON POWER 1
14 ZPC1007GAMW INDICATOR STAND-BY 1
15 H03-ZMC11S12A00 CAP BUTTON STAND-BY AVR 1
16 ZFD122062SB RUBBER TOP AVR 1
17 ZPD2701GAGY
PANEL FRONT AVR - USA
1
17 --- ZPD2801GAGY
PANEL FRONT AVR - 230V
1
18 H03-ZMC11S14A00 BRACKET DOOR 1
19 ZPC1002GAGY DOOR AVR 1
20 H03-ZMD05S16A00 BKT HINGE AVR 2
21 H03-ZPC1018GART FILTER VFD 1
22 H03-ZPD2919GABT
WINDOW DISPLAY AVR645+BADGE NAME
1
23 H03-ZPD0317GACR CAP KNOB VOLUMN 1
24 H03-ZPD0316GASG COVER KNOB 1
25 H03-ZPD0315GAMW VOLUMN KNOB 1
26 H03-ZVC11GEAR01 DAMPER GEAR DP120 1
27 ZPC1102GAMW INDICATOR VIDEO 2
28 ZPC1005GAGY BUTTON 8 KEY 1
29 H03-ZPC1004GASG BUTTON 7 KEY 1
29 --- H03-ZPD1004GASG BUTTON 7 KEY EU 1
30 ZFNR19720SB RUBBER FOOT 19.7X19.7X2T BK 4
31 ZPC1103GAGY FOOT 50MM 15.8MM 4
32 H03-ZMD27S13A00 CHASSIS MAIN AVR 1
33 H03-SORA3313PNN CON PHONOSCKT RCA-313P3PINS 1
34
H03-SORA8OSC5N8
JACK S-VIDEO 1P C40160261N 1
35 H03-ZMC12S17A00 AC PUN SHIELD DIGITAL ET 1
36 H03-SORA1JE01NN JACK RCA 1P JE010003MN GND OR 1
37 H03-SOTORX177LT FIBER OPTIC RECEIVING TORX177L (F, T)
38 H03-SO3P5179NNN JACK PHONE 3.5PI PJ0435179N 1
39 ZFD122072SB RUBBER TOP AVR 3
40 H03-ZMC11S06A00 SPRING STOPPER AVR430/630 1
41 H03-SWE3A0505S1 SWIROT EC 16B24204A9 5V 500UOA 10T 3P 00 1
42 H03-ZMB01S02200 SPRING PLATE GND C5212 0.2T 9
43 H03-ZMD12S01B00 SHIELD MICROPHONE 1
44 H03-XD18BT19GNA VFD 18-BT-19GINK 1
45 ZPC1017GABK HOLDER VFD AVR 1
46 H03-ZMC11S07A00 CHASSIS FRONT AVR 1
47 H03-ICROMN338EC REMOCON RECEIVER MODULE ROM-N338TEC
48 H03-ZVJF0925S00-R-0 DC FAN JF0925S1M-003C651R 12V 92x92x25mm
49 H03-ZMC11S09A00 BKT FAN FRONT AVR 1
50 H03-ZMD27HS0200 H/SINK MAIN AVR745 1
51 H03-ZMC12S08B00 BKT TRANS BOTTOM 1
PART NO.
AVR645
harman/kardon
30
