Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
SURROUND PCB
Capacitors
C204 C206 C304 C306 C504
C506
CCKID0271NN-R CC 270P0F +10% -10% 50.0V 2B4
C207 C307 C507 CCCIC0030NN-R CAP CERAMIC 3PF 50V C CH TAP
C209 C309 C509 CCKIC0181NA-R CC 180P0F +10% -10% 50.0V Y5P
C215 C315 C517 CCKIC0332NA-R CC 3N3F +10% -10% 50.0V Y5P
C607 C608 C611 CCZGC0104NA-R CAP CERAMIC 100NF 25V Z Z5U TAP
C601 C602 C603 CPIKC0473NN-R CPF 47N0F +10% 100.0V
C210 C310 C510 CPJJC0683NN-R CAP POLY NON METAL 68NF 63V J TAP
C208 C308 C508 H03-CEHEC02275E-R CE 220UF +20% 10.0V P=5MM 85C SK 220/10V 5 X11
C205 C305 C505 H03-CEHGC01075E-R CE 100U0F +20% 25.0V 6.3X11 85C P5MM SK 100/25V 6.3 X11
C101 C203 C303 C503 C609
C610 C614
H03-CEHIC01065E-R CE 10U0F +20% 50.0V 85C P5MM 5X11 SK 10/50V 5 X11
C201 C202 C301 C302 C501
C502
H03-CEHJA0477MN-R CE 470U0F +20% 63.0V 85C SK 470/63V 13 X21
C604 CEMFA02285E-R CE 2200UF 16V M 12.5X20 P5MM
C211 C212 C311 C312 C511
C512
H03-CEMKC0106AH-R CAP ELEC 10UF 100V M 6.3X11 SHL
C600 CEMFA0478BK-R CAP ELEC 4700UF 16V M 16X25 85C 120HZ ELITE
C213 C214 C313 C314 C513
C514
H03-CPJJC0104NN-R CAP POLYESTER NON METAL 0.1uF 63V J TAP PCMT365 76104
C606 H03-CEMFA0688BK-R CAP ELEC 6800UF 16V M 16X25 85C 120HZ SK 6800/16V 16 X25
C216 C316 C516 CCKIC0103NA-R CC 10N0F +10% -10% 50.0V Y5P
Semiconductors
Q216 Q316 Q516 H03-TR2SA1859BC-R TR-SHPLF 2SA1859A PNP -2.0A
Q219 Q319 Q519 H03-TR2SA1986AC-R TRANSISTOR PNP 2SA1986-R(AC,F) HFE:55~110
Q217 Q317 Q517 H03-TR2SC4883BC-R TR-SHPLF 2SC4883A NPN 2.0A
Q218 Q318 Q518 H03-TR2SC5358AC-R TRANSISTOR NPN 2SC5358-R(AC,F) HFE:55~110
Q215 Q315Q515 H03-TRKTA1360BE-R TRANSISTOR PNP KTA1360 TO-126
Q214 Q314 Q514 H03-TRKTC3114NE-R TRANSISTOR NPN KTC3114 TO-126
Q213 Q313 Q513 H03-TRKTC3423BE-R TRANSISTOR NPN KTC3423 TO-126
D601 H03-DUKBU6GMF6N-R KBU6G-MF RS-6 Kink Type
IC64 H03-ICKIA278R05-R IC VOLTAGE REGULATOR KIA278R05PI TO-220IS-4
IC61 H03-ICKIA78D3A0-R IC VOLTAGE REGULATOR KIA78D33PI 3.3V TO-220IS
IC63 H03-ICKIA7905I2-R IC-REGNEGFXD KIA7905PI VOLTAGE REGULATOR
D101 D201 D202 D203 D204
D301 D302 D303 D304 D501
D502 D503 D504
H03-DG1N04148NB-R D-SLP 1N4148 100.0V 150E-3A
D602 D605 H03-DR1N04004NA-R D-SR 1N4004 400.0V 1.0A
Q205 Q305 Q505 H03-TR2SA1145YF-R TRANSISTOR PNP 2SA1145-Y(F) TO-92 HFE:120~240
Q208 Q211 Q308 Q311 Q508
Q511
H03-TRKTA1024NA-R TR-SLPLF KTA1024 Y PNP 50MI0A -150V
Q101 Q206 Q306 Q506 H03-TRKTA1268NA-R TR-SHPLF KTA1268BL PNP 100MI0A 120V
Q204 Q304 Q504 H03-TRKTC3198NA-R TR-SLPLF KTC3198BL NPN 150MI0A
Q201 Q202 Q203 Q207 Q220
Q301 Q302 Q303 Q307 Q320
Q501 Q502 Q503 Q507 Q520
H03-TRKTC3200NA-R TR-SHPLF KTC3200BL NPN 100MI0A 120V
Q209 Q212 Q309 Q312 Q509
Q512
H03-TRKTC3206NA-R TR-SLPLF KTC3206 Y NPN 50MI0A 150V
Resistors
R238 R338 R538 H03-RI3IC022BEN-R RW 220MI0 OHM +5% 5.0W 100PPM/'C -100PPM/'C
R245 R345 R545 H03-RM3FC0100BN-R RES METAL OXIDE 10R OHM+5% 1.0W
R601 R602 H03-RM3GC010ACN-R RESISTOR METAL OXIDE 1R0 OHM +5% 2.0W
R603 R604 H03-RM3GC039ACN-R RESISTOR METAL OXIDE 3R9 OHM +5% 2.0W
VR201 VR301 VR501 H03-RT7EA0201NB-R PR 200R0 OHM +20% 500MI0W
R225 R233 R325 R333 R525
R533
H03-RM3EG0100LN-R RMF 10R0 OHM +5% 500MI0W
