Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
VIDEO PCB
N702 H03-WN10SB100WH-R CONNECT WAFER 2.0mm 10P 35336-1010 WHT
P605 H03-WN29AI00000-R CONN 1.25MM 29 FE R WH GF120-29S-LS 2794 A6
BK10 H03-ZMD27S05A00-R BKT IPOD
N611 H03-WN16AI00000-R CONNECT 1.25MM 16P GF120-16S-LS 1.25MM 16P
P603 H03-WN07AD00000-R CONNECT WAFER 2.5MM 7P 5268-07A WHT ANGLE
P612 H03-WN14AI00000-R CONNECT 1.25mm 14P,GF120-14S-LS 1.25mm 14P
N607 H03-WN05SB26000-R WIRE ASS'Y,UL1533/2547#26(TA) 260mm 2.0mm 5P GRY
P604 H03-WN05AB00000-R GIL-S-05P-S2L2-EF 5P
L101 L102 L103 L121 H03-FB05B3580NN-R BEAD AXIAL/TAP,HC3580 80.5ohm
L122 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L109 H03-LALNB056ACR-R INDUCTOR COIL AL02TB5R6J 5.6UH 1.9OHM +5%
L100 L130 L131 L132 L133
L134 L135 L136 L137 L138
L139 L140 L141 L146
H03-FB1212012KF-R FCM2012KF-121T08 120ohm 2012
L110 L112 H03-FB2012F1R5K-R FCI2012F-1R5K 1.5UH 0805
L105 L106 L107 L108 L114
L115 L116 L118 L119 L120
L154
H03-FB2012F3R9K-R FCI2012F-3R9K 3.9UH 0805
L111 L113 H03-LS2012F1R8K-R INDUCTOR COIL FCI2012F-1R8K 1.8UH 0805
L142 L143 L144 L145 H03-LS2012H9002-R CHOKE COIL ACM2012H-900-2P
NJ60 H03-SO1R018H91E-R DA1R018H91E
NJ17 NJ18 NJ19 H03-SOYKF457009-R JACK HDMI YKF45-7009 JALCO
F100 H03-SWNANDC1502-R SWITCH POLY NANOSMDC150F-2 SMD
Y103 H03-OSX27MSCOB0-R CRYSTAL,27.000MHz SCO-103 25-27.000M
MECHANICAL ASSEMBLY
H03-TXPWMEI95B0-R SW PUSH POWER SDDLB15700
H03-TXPWMEI95B0-R POWER TRANSFORMER AVR645 MAIN TRANS 120V 60Hz US
H03-TXPWMEI93B0-R POWER TRANSFORMER AVR645 MAIN TRANS 230V 50Hz EU
H03-WF22S2605RT-R DHCDT-22/260-P1.25-RT(5/5,10/10)
H03-WG02SG8532A-R WIRECONASY UNIQUE 2P 530MM UL1617 PVC DBL INSULATED
H03-WG04SB81400-R UL1007#26 STR 140mm 2.0mm 4P WHT
H03-WN29SI02000-R WIRE FFC(CARD CABLE) DHCDT-29/200-P1.25-ST(5/5,10/10)
H03-ZMB01S00100-R BKT HEADPHONE
H03-ZMB01S02200-R SPRING PLATE GND C5212 0.2T
H03-ZMC11S00200-R AL DOOR AVR
H03-ZMC11S04B00-R BKT FRAME GUIDE
H03-ZMC11S06A00-R SPRING STOPPER AVR
H03-ZMC11S07A00-R CHASSIS FRONT AVR
H03-ZMC11S09A00-R BKT FAN FRONT AVR
H03-ZMC11S10A00-R BKT FAN REAR AVR
H03-ZMC11S12A00-R CAP BUTTON STAND-BY AVR
H03-ZMC11S14A00-R BRACKET DOOR
H03-ZMC12S07A00-R COVER BOTTOM
H03-ZMC12S08B00-R BKT TRANS BOTTOM
H03-ZMC12S09A00-R BKT HEATSINK
H03-ZMC12S19A00-R BKT AC INLET
H03-ZMD05S16A00-R BKT HINGE AVR7300
H03-ZMD2701ZANI-R BRACKET POSISTOR,METAL,AVR
H03-ZMD2702GAGY-R AL PANEL FRONT,AVR
H03-ZMD2703GAGY-R BADGE FRONT,AL,AVR,GREY,HOT STAMPING
H03-ZMD27HS0100-R H/SINK AMP AVR
H03-ZMD27HS0200-R H/SINK MAIN AVR
H03-ZMD27HS0300-R HEATSINK AMP SMALL
H03-ZMD27S04A00-R BKT FRAME GUIDE AVR
H03-ZMD27S06A00-R BKT VIDEO
H03-ZMD27S08A00-R COVER TOP AVR
H03-ZMD27S13A00-R CHASSIS MAIN AVR
H03-ZMD27S20A00-R BADGE harman/kardon COVER TOP AVR
H03-ZMD29S02A00-R PANEL REAR AVR645US
H03-ZPC1004GASG-R BUTTON 7 KEY
H03-ZPC1018GART-R FILTER VFD
AVR645
harman/kardon
122
