Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
VIDEO PCB
R123 R124 R125 R127 R128
R129 R131 R132 R133 R135
R136 R137 R139 R140 R141
R160 R161 R170 R171 R172
R347 R351
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R144 R145 R146 R159 R169
R212 R213 R214 R220 R221
R222 R311 R312 R313 R342
R349 R350 R353 R354 R360
R361 R606 R610 R611
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R615 RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R154 R155 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R112 R113 R114 R115 R116
R117 R118 R119 R147 R148
R157 R158 R184 R185 R215
R216 R227 R228 R229 R264
R265 R266 R276 R389 R390
RS3AD010ANA-R RES CHIP,1R 1/16W +/-5%,0603
R162 R187 R188 R226 RS3AD0121NA-R RMGCFMIC 120R0 OHM +5% 0603
R130 R134 R138 R142 RS3AD0123NA-R RES CHIP,12K 1/16W +/-5%,0603
R167 R612 RS3AD0124NA-R RES CHIP,120K 1/16W +/-5%,0603
R474 RS3AD0150NA-R RES,CHIP 15 OHM +/-5%,1/16W, 0603
R150 RS3AD0154NA-R RMGCFMIC 150K0 OHM +5% 0603
R343 R344 RS3AD0182NA-R RES CHIP,1.8K,1/16W,+-5%,0603.
R248 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R348 R352 R607 R608 RS3AD0223NA-R RES CHIP,22K 1/16W +/-5%,0603
R166 R609 RS3AD0224NA-R RES CHIP,220K 1/16W +/-5%,0603
R149 RS3AD0271NA-R RMGCFMIC 270R0 OHM +5% 0603
R365 RS3AD0302NA-R RMGCFMIC 3K0 OHM +5% 0603
R249 RS3AD0333NA-R RMGCFMIC 33K0 OHM +5% 0603
R367 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R181 R182 R183 R207 R362
R380 R614
RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R120 RS3AD0471NA-R RMGCFMIC 470R0 OHM +5% 0603
R175 R176 R280 R281 R284
R285 R337 R338 R364
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R604 R605 R613 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R156 RS3AD0624NA-R RES,CHIP 620K 1/16W +/-5% 0603
R235 RS3AD0820NA-R RMGCFMIC 82R0 OHM +5% 0603
R143 RS3AD0822NA-R RMGCFMIC 8K2 OHM +5% 0603
RA10 RA11 RA12 RA13 RA16
RA17 RA18 RA19 RA22 RA33
RA34 RA35 RA36 RA39
RS3AY0470NA-R RES NETWORK RCA 47R0 OHM +5% 62M15W CN34JT470
RA30 RA31 RA32 RN3AY0220NA-R RES NETWORK RCA 22OHM 1/16W 5% CN34JT220
R372 R373 R374 R375 R376
R377
RS1AD3000NA-R RES.CHIP 300R 1/16W +/-1% 0603
R473 RS1AD049ANA-R RES.CHIP 4.99OHM 1/16W +/-1% 0603
R476 R477 RS1AD301ANA-R RES.CHIP 30.1R 1/16W +/-1% 0603
R121 RS3AD024ANA-R RESISTOR CHIP 2R4 OHM 1/16W 5% 0603
Miscellaneous
Y100 H03-OSXBE14M39S-R CRYSTAL 14.31818MHZ HC-49/S WOOIN
Y101 H03-OSXBE17M79S-R CRYSTAL 17.734475MHZ HC-49/S WOOIN
Y104 H03-OSXBE28M39S-R CRYSTAL 28.322MHz 18pF HC-49/S
K100 K101 K102 K103 H03-RLL0517811A-R RELAY D3009(1-1462033-4)
NJ16 H03-SOR12BJ12NN-R JACK RCA 12P BJ120154JN
NJ10 NJ11 H03-SORA60031YN-R JACK RCA+S-VIDEO 6P C8030031YN
P602 H03-WN04AB00000-R CONN 2.0MM GIL-S-04P-S2L2-EF 4P
P700 P701 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
N700 N701 H03-WN04SB100WH-R CONN WAFER 2.0MM 4P 35336-0410 WHT
P601 H03-WN06AB00000-R CONNECT 2.0mm 6P GIL-S-6P-S2L2-EF
N608 P702 H03-WN10AB000WH-R CONNECT WAFER 2.0mm 10P 35237-1010 WHT
AVR645
harman/kardon
121
