Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
VIDEO PCB
IC23 IC28 IC31 H03-ICTSH95IDB4-R IC-VIDEOPROC TSH95ID VIDEO AMPLIFIER
Q119 Q120 H03-TS2N7002LND-R MOSFET N-CHANNEL 2N7002LT1G SOT-23
Q101 H03-TRKTC3875ND-R TRANSISTOR NPN KTC3875S SOT23
Q110 Q111 Q112 H03-TSKRA107SNI-R KRA107S SOT-23 PNP
Q103 Q104 Q105 Q106 Q113
Q114 Q115 Q118
H03-TSKRC107SND-R KRC107S SOT-23 NPN
IC41 IC44 IC58 H03-TSUPA672TNH-R TRANSISTOR MOSFET N-CHANNEL UPA672T-T1-A SMD
IC56 IC57 IC61 IC62 H03-DSAMP0514MN-R DIODE TVS ARRAY RCLAMP0514M MSOP-10L
IC10 H03-ICIL1117SDG-R IC LOW DROP REGULATOR IL1117S-1.8 1.8V SOT-223
D608 H03-DSKDZ3V30NB-R DIODE ZENER,KDZ3.3EV KEC
IC27 H03-ICLC74763ME-R LC74763M-9602-E SOP30 On-Screen Display LSI
Resistors
R191 R192 R618 R619 RS1AD0750NA-R RES CHIP 75OHM 1% 1/16W 0603
R153 RS1AD1691NA-R RES CHIP 1K69 ohm 1/16W 1% 0603
R288 R291 R294 R298 R301
R302 R304 R357 R602 R603
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R358 R359 RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R251 R255 R258 R371 RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R164 R223 R224 R225 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R173 R174 R334 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R230 R231 RS3AD010ANA-R RES CHIP,1R 1/16W +/-5%,0603
R126 RS3AD0123NA-R RES CHIP,12K 1/16W +/-5%,0603
R165 RS3AD0152NA-R RES CHIP 1K5 1/16W +5% 0603
R252 R253 R256 R259 RS3AD0153NA-R RES CHIP,15K 1/16W,+/-5%,0603.
R339 RS3AD0201NA-R RES.CHIP,200 1/16W +-5%,0603.
R261 R263 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R151 R152 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R368 RS3AD0302NA-R RMGCFMIC 3K0 OHM +5% 0603
R335 RS3AD0330NA-R RMGCFMIC 33R0 OHM +5% 0603
R260 R262 RS3AD0333NA-R RMGCFMIC 33K0 OHM +5% 0603
R369 RS3AD0390NA-R RES,CHIP 39 OHM 1/16W +/-5% 0603
R206 R336 RS3AD0470NA-R RMGCFMIC 47R0 OHM +5% 0603
R208 R282 R283 R333 R345
R346 R381 R382
RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R247 R250 RS3AD0680NA-R RMGCFMIC 68R0 OHM +5% 0603
R370 RS3AD0681NA-R RES CHIP,680R 1/16W +/-5%,0603
R163 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
R254 R257 RS3AD0752NA-R RES CHIP 7.5K,1/16W,+-5%,0603.
R186 RS3AD0301NA-R RES,CHIP 300 OHM 1/16W +/-5% 0603
R400 R401 R402 R403 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R478 RS1AD0101NA-R RES CHIP 100 OHM 1/16W 1% 0603
R500 RS3AD0682NA-R RMGCFMIC 6K8 OHM +5% 0603
RV16 RV17 RV18 RV19 RV20
RV21 RV22 RV23
H03-VR0402V275R-R VARISTOR CHIP CT0402V275RFG 16V
RV10 RV11 RV12 RV13 RV14
RV15
H03-VR0603V150R-R VARISTOR CHIP CT0603V150RFG
R100 R101 R102 R103 R105
R106 R107 R108 R109 R110
R111 R189 R190 R210 R217
R218 R219 R233 R234 R237
R238 R239 R240 R241 R242
R243 R244 R245 R246 R267
R268 R269 R270 R271 R272
R273 R274 R275 R277 R278
R279 R383 R384 R385 R386
R387 R388 R617
RS1AD0750NA-R RES CHIP 75OHM 1% 1/16W 0603
R332 RS1AD4750NA-R RES.CHIP 475 OHM 1/16W +/-1% 0603
R601 RS1AD5493NA-R RES,CHIP 549K 1/16W +/-1% 0603
R104 R209 R211 R232 R236 RS1AD787ANA-R RES CHIP 78.7 ohm 1/16W 1% 0603
R286 R292 R296 R355 R475 RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R168 R177 R178 R179 R180
R330 R331 R340 R341 R378
R379
RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
AVR645
harman/kardon
120
