Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
SURROUND PCB
R243 R299 R343 R399 R543
R599
RC3DI0100IN-R RCF 10R0 OHM +5% 250MI0W
R226 R236 R326 R336 R526
R536
RC3DI0101IN-R RCF 100R0 OHM +5% 250MI0W
R101 R605 RC3DI0103IN-R RCF 10K0 OHM +5% 250MI0W
R246 R346 R546 RC3DI0104IN-R RCF 100K0 OHM +5% 250MI0W
R228 R235 R328 R335 R528
R535
RC3DI0150IN-R RCF 15R0 OHM +5% 250MI0W
R239 R241 R339 R341 R539
R541
RC3DI0152IN-R RCF 1K5 OHM +5% 250MI0W
R220 R221 R240 R320 R321
R340 R520 R521 R540
RC3DI0153IN-R RCF 15K0 OHM +5% 250MI0W
R209 R210 R309 R310 R509
R510
RC3DI0162IN-R RCF 1K6 OHM +5% 250MI0W
R219 R222 R223 R224 R319
R322 R323 R324 R519 R522
R523 R524
RC3DI0201IN-R RCF 200R0 OHM +5% 250MI0W
R205 R206 R207 R305 R306
R307 R505 R506 R507
RC3DI0221IN-R RCF 220R0 OHM +5% 250MI0W
R244 R344 R544 RC3DI0223IN-R RCF 22K0 OHM +5% 250MI0W
R227 R237 R327 R337 R527
R537
RC3DI022AIN-R RCF 2R2 OHM +5% 250MI0W
R229 R329 R529 RC3DI0282IN-R RCF 2K8 OHM +5% 250MI0W
R201 R301 R501 RC3DI0331IN-R RCF 330R0 OHM +5% 250MI0W
R202 R302 R502 RC3DI0333IN-R RCF 33K0 OHM +5% 250MI0W
R102 R242 R342 R542 RC3DI0393IN-R RCF 39K0 OHM +5% 250MI0W
R204 R304 R504 RC3DI0433IN-R RCF 43K0 OHM +5% 250MI0W
R208 R308 R508 RC3DI0471IN-R RCF 470R0 OHM +5% 250MI0W
R211 R214 R215 R216 R217
R218 R311 R314 R315 R316
R317 R318 R511 R514 R515
R516 R517 R518
RC3DI0561IN-R RCF 560R0 OHM +5% 250MI0W
R234 R334 R534 RC3DI0820IN-R RCF 82R0 OHM +5% 250MI0W
R230 R330 R530 RC3DI0751IN-R RCF 750R0 OHM +5% 250MI0W
R213 R313 R513 RM1DI0152IN-R RMF 1K5 OHM +1% 250MI0W
R212 R312 R512 RM1DI0333IN-R RMF 33K0 OHM +1% 250MI0W
Miscellaneous
L201 L301 L501 H03-LCNNNA050NA-R LFA 1MM 10MM 5 LEFT 0.0MM NONE SP-2516
NJ401 H03-SOPA8SH0612-R JACK SPEAKER 6P SH0612707P GN BN TA
N502 H03-WG06SE81200-R WIRE ASS'Y UL1007#16 120mm 3.96mm 6P RED
P201 P301 P501 H03-WN02AD00000-R CONNECT WAFER 2.5mm 2P 5268-02A WHT ANGLE
P506 H03-WN03SB00000-R CONNECT 2.0mm 3P GIL-S-3P-S2T2-EF
N503 H03-WN03SD100WH-R CONN WAFER 2.5MM 3P 5267-03A WHT
N504 H03-WN05SB00000-R CONNECT 2.0mm 5P GIL-S-5P-S2T2-EF
N505 H03-WS6262605EN-R WIRECONASY DL 2.0MM 6P 260MM UL1533 SHIELD 26 1
N501 H03-WG07AD02700-R WIRE ASS'Y,UL1007#20(TA) 270mm 2.5mm 7P WHT
H03-ZH740MSQ6WH-R MICA SHEET SIZE 19X22X0.05
F601 F602 H03-FURN23150SR-R FUSE SR-5 SERIES 3821315 SR-5-3.15A 250V 35A
G101 G102 G105 H03-ZNMSA4004SN-R TERMLUG GND
VIDEO PCB
Capacitors
C252 CPIIC0223NN-R CPF 22N0F +10% 50.0V
C514 CPIIC0682NN-R CPF 6N8F +10% 50.0V
C101 C103 C283 C284 H03-CEHDC0108NN-R CE 1000UF +20% 6.3V 8X11.5 85C P5MM
C104 C105 C106 C109 C111
C112 C114 C115 C117 C118
C120 C130 C167 C172
H03-CEHEC02275E-R CE 220UF +20% 10.0V P=5MM 85C SK 220/10V 5 X11
AVR645
harman/kardon
117
