Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
VIDEO PCB
C128 C129 C131 C132 C133
C134 C135 C136 C169 C170
C270 C271 C278 C279
H03-CEHEC0477MN-R CE 470U0F +20% 10.0V 85C P=5MM SK 470/10V 6.3 X11
C601 C604 C607 H03-CEHFC01062S-R CE 10UF +20% 16V D4XL7 P2.5MM 2000hours 85C
C243 C245 C251 C257 C277
C288 C292 C296 C300 C304
C308 C349 C356 C536
CEHFC0107NN-R CE 100U0F +20% 16.0V 85C
C145 C150 C155 C160 C165
C285 C310 C313 C331 C333
C337 C342
H03-CEHFC04765E-R CE47UF +20% 16.0V D5XL11 P5MM 85C SK 47/16V 5 X11
C249 C255 C265 C290 C294
C295 C298 C299 C302 C303
C306 C307 C606
H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C100 C102 C107 C108 C110
C113 C116 C119 C168 C182
C185 C188 C190 C195 C204
C210 C239 C240 C241 C276
C286 C316 C317 C318 C319
C320 C321 C322 C323 C324
C353 C354 C360 C535
H03-CEHIC01065E-R CE 10U0F +20% 50.0V 85C P5MM 5X11 SK 10/50V 5 X11
C351 C352 C359 H03-CEHIC02255E-R CE 2U2F +20% 50V D5XL11 P5MM 85C SK 2.2/50V 5 X11
C439 C448 C467 H03-CEMFC0226NN-R CAP ELEC 22UF 16V M P5MM SK 22/16V 5 X11
C171 CCKIC0121NA-R 120pF 50V Y5P +10% P=5.0MM
C248 H03-CEHIC0474NN-R CE 0.47UF +20% 50.0V 85C 5X11 P5MM
C430 C460 C464 C482 C483
C506 C509 C517
CTMFJ0106ZN-R CAP TANTAL/CHIP 10uF 16V T491B106K016AS 3528
C141 C142 C143 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C491 C492 CZJII0180BE-R CAP CHIP 18PF 50V CH J NP0 0603
C275 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C261 C262 C263 C264 CZJII0390BE-R CAP CHIP 39PF 50V CH J NPO 0603
C193 CZKFI0823BC-R CAP CHIP 82NF +/-10% 16V 0603 X7R
C444 C445 C446 C454 C455
C456 C457 C458 C462 C466
C471 C472 C498 C499 C504
C505 C508 C511
CZKII0102BC-R CAP CHIP 1N0F +10% -10% 50.0V X7R 0603
C184 C187 C197 C199 C201
C206 C212 C214 C230 C232
C235 C250 C347 C493 C494
C518
CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C523 CZKII0392BC-R 3n9F 50V X7R K 0603
C194 CZKII0822BC-R CAP CHIP 8N2F +10% -10% 50.0V X7R 0603
C144 C149 C154 C159 C164
C180 C183 C186 C189 C191
C196 C198 C200 C205 C211
C213 C229 C231 C233 C244
C246 C256 C289 C293 C297
C301 C305 C309 C311 C312
C314 C315 C325 C327 C332
C334 C336 C338 C339 C343
C357 C361 C362 C363 C431
C432 C433 C434 C435 C436
C437 C440 C441 C442 C443
C449 C450 C451 C452 C453
C461 C465 C468 C469 C470
C475 C476 C477 C478 C479
C480 C481 C484 C485 C486
C487 C488 C489 C490 C496
C497 C501 C502 C507 C510
C512 C519 C520 C521
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C207 C473 C474 C495 CTMFJ0106ZN-R CAP TANTAL/CHIP 10uF 16V T491B106K016AS 3528
C247 CZDII0100BE-R CAP CHIP 10PF 50V CH D NP0 0603
C236 C237 C267 C268 C269
C282
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C273 C340 CZJII0220BE-R CCCFMIC 22P0F +5% -5% 50.0V NP0
C254 CZJII0270BE-R CAP CHIP 27P0F +5% -5% 50.0V NP0 0603
C253 CZJII0300BE-R CAPA CHIP 30PF 50V CH NP0 +5% 0603
AVR645
harman/kardon
118
