Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
MAIN PCB ASS'Y
NJ84 SO0A18P8CNN-R JACK-TELE SNAP-IN GOLDEN TELECOM GDL1-8P8C 8T BK 0 0
ZNSSM3023HZ-R NUT M3 ZN PLATED
ZSMBM3014BZ-R SCREW M.S M3X14 ZN PLATED
ZSTBM3010BB-R SCREW ST BH 3X10
N706 H03-WG02SD03801-R WIRE ASS'Y,UL1007#24(TA) GRY 380mm 2.5mm 2P US
N807 H03-WG05AB81900-R WIRE ASS'Y UL1007#26(TA)190MM 2.0MM 5P WHT
H03-ZH740MSQ6WH-R MICA SHEET SIZE 19X22X0.05
PO71 H03-ICLM19CIZIE-R IC TEMPERATURE SENSOR LM19CIZ 2.4V TO-92
PROCESSOR PCB
Capacitors
C125 C126 C127 C128 C141
C143 C144 C146 C190 C191
C206 C207 C212 C213 C220
C221 C226 C227 C230 C231
C232 C233 C251 C252 C253
C254 C301 C302 C303 C304
C307 C308 C309 C310 C508
C510 C517 C518 C521 C522
C528 C529 C534 C535 C601
C602 C611 C612 C617 C618
C621 C622 C627 C628 C631
C632 C637 C638 C641 C642
C647 C648
CEHFC0106NN-R CE 10U0F +20% 16.0V 85C
C175 C176 C193 CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C
C607 C608 H03-CEMGC0337AH-R CAP ELEC 330UF 25V M 8X11.5 AHS
C214 C215 C609 C610 CEHFC0107NN-R CE 100U0F +20% 16.0V 85C
C101 C102 C103 C104 C116
C117 C118 C119 C121 C122
C123 C124 C131 C132 C133
C134 C136 C137 C138 C139
C147 C148 C149 C150 C152
C153 C154 C155 C156 C157
C158 C159 C194 C195 C196
C197 C201 C202 C204 C205
C210 C211 C216 C217 C218
C219 C531 C603 C604
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C281 C282 CZJII0121BE-R CAP CHIP 120PF 50V J NPO 0603
C208 C209 C222 C223 C624
C644
CZJII0151BE-R CAP CHIP 150PF 50V J NPO 0603
C532 C533 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C12 C13 C14 C15 C16 C17
C18 C19 C120 C135 C203
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C224 C225 C238 C315 C316
C503 C506 C519 C520 C530
C540
CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
C591 C592 C613 C614 C623
C633 C643
CZJII0151BE-R CAP CHIP 150PF 50V J NPO 0603
C605 C606 CZJII0271BE-R CAP CHIP, 270PF 50V +/-5% CH J 0603
C615 C616 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
C634 C636 CZKII0222BC-R CAP CHIP 2N2F +10% -10% 50.0V X7R 0603
C10 C11 C20 C21 CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C625 C626 C635 C645 C646 CZJII0560BE-R CAP CHIP 56PF 50V CH J NPO 0603
Semiconductors
IC2 IC3 IC4 IC5 IC6 IC7 IC10
IC11 IC25
H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
IC1 H03-ICNJM4580D2-R IC OP AMP NJM4580M-TE1 SOP8 DUAL OP-AMP
IC8 H03-ICTC9273CFG-R TC9273CFG-004 SOP28 ANALOG SWITCH ARRAY ICs
Q601 Q602 Q621 Q622 Q624
Q625 Q627 Q628 Q630 Q631
H03-TRKTD1304ND-R TR-SLPSWA KTD1304 NPN 20V 300MI0A SOT-23
AVR645
harman/kardon
111
