Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
MAIN PCB ASS'Y
R339 R340 R345 R346 R347
R348 R349 R350 R433 R434
R435 R436 R441 R442 R443
R444
RC3DI0201IN-R RCF 200R0 OHM +5% 250MI0W
R215 R317 R318 R319 R320
R321 R322 R409 R410 R411
R412 R413 R414
RC3DI0221IN-R RCF 220R0 OHM +5% 250MI0W
R390 R391 R486 R492 RC3DI0223IN-R RCF 22K0 OHM +5% 250MI0W
R107 R108 R371 R372 R373
R374 R465 R466 R467 R468
R616
RC3DI022AIN-R RCF 2R2 OHM +5% 250MI0W
R497 RC3DI0271IN-R RCF 270R0 OHM +5% 250MI0W
R209 R498 R506 RC3DI0273IN-R RCF 27K0 OHM +5% 250MI0W
R224 RC3DI0274IN-R RCF 270K0 OHM +5% 250MI0W
R701 R707 R710 R711 RC3DI0282IN-R RCF 2K8 OHM +5% 250MI0W
R301 R302 R401 R402 RC3DI0331IN-R RCF 330R0 OHM +5% 250MI0W
R225 R305 R306 R403 R404
R509 R515
RC3DI0333IN-R RCF 33K0 OHM +5% 250MI0W
R382 R383 R484 R487 R491 RC3DI0393IN-R RCF 39K0 OHM +5% 250MI0W
R307 R308 R415 R416 RC3DI0433IN-R RCF 43K0 OHM +5% 250MI0W
R101 R102 R105 R106 R109
R110 R113 R114 R315 R316
R593 R594 R718
RC3DI0471IN-R RCF 470R0 OHM +5% 250MI0W
R223 RC3DI0513IN-R RCF 51K0 OHM +5% 250MI0W
R323 R324 R325 R326 R329
R330 R333 R334 R335 R336
R337 R338 R421 R422 R423
R424 R425 R426 R427 R428
R429 R430 R431 R432
RC3DI0561IN-R RCF 560R0 OHM +5% 250MI0W
R375 R376 R469 R470 RC3DI0820IN-R RCF 82R0 OHM +5% 250MI0W
R702 R705 R708 R709 RC3DI0751IN-R RCF 750R0 OHM +5% 250MI0W
R493 RC3DI0822IN-R RCF 8K2 OHM +5% 250MI0W
R331 R332 R419 R420 RM1DI0152IN-R RMF 1K5 OHM +1% 250MI0W
R327 R328 R417 R418 RM1DI0333IN-R RMF 33K0 OHM +1% 250MI0W
VR71 VR72 VR73 RT6BA0201NB-R PR 200R0 OHM +30% 100MI0W
Miscellaneous
NJ81 H03-SOPA81900NN-R CONN-SPE TERMINAL SPKR 8P SH081136JP FE 19MM 8 -- 0 0
NJ83 H03-SORA40RSANN-R JACK RCA 4P JB040131ZN GN BN PP TA
NJ82 H03-SORA40RSCNN-R JACK RCA 4P JB040131QN WH BU RD GY
L301 L302 L401 L402 H03-LCNNNA050NA-R LFA 1MM 10MM 5 LEFT 0.0MM NONE SP-2516
N814 H03-WG03SE03700-R WIRE ASS'Y UL1007#16(TA) 370mm 3P GRY
P503 P805 P806 P809 P817
P818
H03-WN02SD00000-R CONN 2.5MM 2 MA ST NAT 5267-02A 0 0
N819 N820 N821 N823 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
P801 P802 P803 P804 H03-WN04SB100WH-R CONN WAFER 2.0MM 4P 35336-0410 WHT
P808 H03-WN05SD100WH-R CONN WAFER 2.5MM 5P 5267-05A WHT
P815 H03-WN07SB100WH-R CONN WAFER 2.0MM 7P 35336-0710 WHT
N822 H03-WN09AB100WH-R CONNECT WAFER 2.0mm 9P 35237-0910 WHT
P811 H03-WN09SB100WH-R CONNECT WAFER 2.0mm 9P 35336-0910 WHT
P816 H03-WN10SB100WH-R CONNECT WAFER 2.0mm 10P 35336-1010 WHT
P812 H03-WN13SB00000-R CONN 2.0MM 13P GIL-S-13P-S2T2
P813 H03-WN19SB00000-R CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
H03-ZMD27HS0400-R H/SINK REG. TR
F501 F502 F505 F506 H03-FURN22000SR-R FUSE SR-5 SERIES 3821200 SR-5-2A 250V 35A
F701 F702 H03-FURN23150SR-R FUSE SR-5 SERIES 3821315 SR-5-3.15A 250V 35A
AVR645
harman/kardon
110
