Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
FRONT PCB ASS'Y
L700 H03-FB2522012HF-R FCM2012HF-252T02 2500ohm SURFACE MT 2012
S201 S202 S203 S204 S205
S206 S207 S208 S209 S210
S211 S212 S213 S214 S215
S216 S217 S218 S219 S220
H03-SWC2A112FS1-R SWITACT VERTICAL SKQNADD010
MAIN PCB ASS'Y
Capacitors
C517 CEHIA0228MN-R CE 2MI2F +20% 50.0V 85C
C571 C572 H03-CEMJA0159KA-R CAP ELEC 15000uF 63V M 35x50 LSW153M1JQ50M
C101 C102 C103 C104 C107
C108 C109 C110 C111 C112
C113 C114 C115 C116 C117
C118 C205
CCKID0101NA-R CC 100P0F +10% -10% 50.0V Y5P
C307 C308 C313 C314 C403
C404 C569 C570
CCKID0271NN-R CC 270P0F +10% -10% 50.0V 2B4
C433 CCMFD0103NN-R CC 10N0F +20% -20% 16.0V Y5S
C119 C120 C203 C212 C214
C527 C531 C709 C711 C712
C713
CCZID0104NA-R CC 100N0F +80% -20% 50.0V F
C315 C316 C409 C410 CCCIC0030NN-R CAP CERAMIC 3PF 50V C CH TAP
C317 C318 C411 C412 CCKIC0181NA-R CC 180P0F +10% -10% 50.0V Y5P
C329 C330 C425 C426 CCKIC0222NA-R CC 2N2F +10% -10% 50.0V Y5P
C707 CCZGC0104NA-R CAP CERAMIC 100NF 25V Z Z5U TAP
C323 C324 C430 C431 CFLJC0683NN-R CPM 68N0F +5% 63.0V
C506 C507 C508 C516 C528
C529 C701 C702 C703
CPIKC0473NN-R CPF 47N0F +10% 100.0V
C331 C332 C407 C408 H03-CEHEC02275E-R CE 220UF +20% 10.0V P=5MM 85C SK 220/10V 5 X11
C206 C208 C213 C309 C310
C405 C406 C526 C710
H03-CEHGC01075E-R CE 100U0F +20% 25.0V 6.3X11 85C P5MM SK 100/25V 6.3 X11
C210 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C301 C302 C401 C402 C518
C519 C521 C530 C708 C429
H03-CEHIC01065E-R CE 10U0F +20% 50.0V 85C P5MM 5X11 SK 10/50V 5 X11
C207 H03-CEHIC04755E-R CE 4U7F +20% 50.0V 85C P5MM SK 4.7/50V 5 X11
C303 C304 C305 C306 C421
C422 C423 C424
H03-CEHJA0477MN-R CE 470U0F +20% 63.0V 85C SK 470/63V 13 X21
C432 H03-CEMGC04775E-R CE 470U0F +/-20% 25.0V 10X13 85C SK 470/25V 10 X13
C211 C319 C320 C321 C322
C413 C414 C415 C416
H03-CEMKC0106AH-R CAP ELEC 10UF 100V M 6.3X11 SHL
C573 H03-CEMDC0478KA-R CAP ELECTROYTIC 4700UF 6.3V M 12.5X21 (SKP472M0JI21R)I
C325 C326 C327 C328 C417
C418 C419 C420
H03-CPJJC0104NN-R CAP POLYESTER NON METAL 0.1uF 63V J TAP PCMT365 76104
C509 C510 H03-CEHHC0228MN-R CE 2200UF +20% 35.0V 85C 16X25
C705 C706 H03-CEMFA0688BK-R CAP ELEC 6800UF 16V M 16X25 85C 120HZ SK 6800/16V 16 X25
C333 C335 C336 C434 CCKIC0103NA-R CC 10N0F +10% -10% 50.0V Y5P
C105 C106 CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C201 C202 CZJII0101BE-R CAP CHIP 100P0F +5% -5% 50.0V NP0 0603
Semiconductors
D502 D505 H03-DU2W04MMF00-R DIODE 2W04M-MF RC-2 Kink Type
D701 H03-DUKBU6GMF6N-R KBU6G-MF RS-6 Kink Type
IC73 H03-ICKIA278R06-R IC VOLTAGE REGULATOR KIA278R06PI TO-220IS-4
IC71 H03-ICKIA278R33-R IC VOLTAGE REGULATOR KIA278R33PI TO-220IS-4
IC72 H03-ICKIA7805I2-R IC-REGPOSFXD VOLTAGE REGULATOR KIA7805API TO-220IS
IC59 H03-ICKIA7812I2-R IC-REGPOSFXD VOLTAGE REGULATOR KIA7812API
IC54 H03-ICKIA7824I2-R IC-REGPOSFXD VOLTAGE REGULATOR KIA7824API TO-220IS
IC51 IC60 H03-ICLM07815BD-R IC-REGPOSFXD VOLTAGE REGULATOR KIA7815API
IC52 H03-ICLM07915BD-R IC-REGNEGFXD VOLTAGE REGULATOR KIA7915API TO-220AB
Q329 Q330 Q433 Q434 H03-TR2SA1859BC-R TR-SHPLF 2SA1859A PNP -2.0A
Q335 Q336 Q439 Q440 H03-TR2SA1986AC-R TRANSISTOR PNP 2SA1986-R(AC,F) HFE:55~110
Q331 Q332 Q435 Q436 H03-TR2SC4883BC-R TR-SHPLF 2SC4883A NPN 2.0A
