Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
FRONT PCB ASS'Y
R120 R121 RC3DI0471IN-R RCF 470R0 OHM +5% 250MI0W
R751 RC3DI0473IN-R RCF 47K OHM +5% 250MI0W
R851 R852 RC3DI0561IN-R RCF 560R0 OHM +5% 250MI0W
R505 R841 R842 R843 R844
C724
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R521 R522 R722 R746 RS3AD0101NA-R RES CHIP,100R 1/16W +/-5%,0603
R201 R211 R503 R515 R721
R824
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R702 R704 R709 R822 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R516 RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R706 R707 RS3AD0105NA-R RES CHIP 1M 1/16W +5% 0603
R202 R212 RS3AD0122NA-R RMGCFMIC 1K2 OHM +5% 0603
R203 R213 RS3AD0152NA-R RES CHIP 1K5 1/16W +5% 0603
R209 R219 RS3AD0183NA-R RMGCFMIC 18K0 OHM +5% 0603
R823 RS3AD0221NA-R RMGCFMIC 220R0 OHM +5% 0603
R204 R214 R510 R519 RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R205 R215 R703 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R206 R216 R506 RS3AD0332NA-R RMGCFMIC 3K3 OHM +5% 0603
R509 RS3AD0472NA-R RES CHIP,4K7 1/16W +/-5%,0603
R520 RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R207 R217 RS3AD0562NA-R RMGCFMIC 5K6 OHM +5% 0603
R821 RS3AD0563NA-R RES CHIP, 56K 1/16W +/-5%, 0603.
R301 R302 R701 RS3AD0683NA-R RMGCFMIC 68K0 OHM +5% 0603
R208 R218 RS3AD0822NA-R RMGCFMIC 8K2 OHM +5% 0603
R508 RS3AD0911NA-R RMGCFMIC 910 OHM +5% 0603
R705 RS3BB0564NA-R RES,CHIP,560K OHM,1/10W +/-5%,0805
R461 R462 RS3AD0753NA-R RES CHIP 75K 1/16W +-5% 0603.
Miscellaneous
VR10 H03-SWE3A0505S1-R SWIROT EC16B24204A9 5V 500U0A 10T 3P 0 0
NJ71 H03-SO3P5179NNN-R JACK PHONE 3.5PI PJ0435179N
NJ70 H03-SORA1JE01NN-R JACK RCA 1P JE010003MN GND OR
NJ11 H03-SORA3313PNN-R CON PHONO SCKT RCA-313P 3 PINS
NJ12 H03-SORA8OSC5N8-R JACK S-VIDEO 1P C40160261N
NJ10 H03-SOSS9CKX3NN-R JACK PHONE 6.35 H70980110S 9P BK
NJ79 H03-SOTORX177LT-R FIBER OPTIC RECEIVING TORX177L (F, T)
N207 H03-WE11B041000-R WIRE ASS`Y UL1007#26 410MM 2.0MM 11P WHT
N201 H03-WG03AB80900-R WIRECONASY DL 2.0MM 03P 90MM ANG-DOWN UL1007 RIBBON 26 1
B20
N206 H03-WG05SB83500-R WIRE ASS'Y UL1007#26(TA) 350mm 2.0mm 5p GRY
N203 H03-WG13SB82000-R UL1007#26 STR 200mm 2.0mm 13P WHT
P213 H03-WN04SB00000-R CONNECT 2.0mm 4P GIL-S-4P-S2T2-EF
P215 H03-WN06SB01000-R CNT PLUG BD'BD PLUG 2.0mm 35336-0610
P209 H03-WN07AB00000-R CONNECT 2.0MM 7P GIL-S-07P-S2L2-EF
N214 H03-WN19AB00000-R CONN 2.0MM 19 MA R NAT SOCKET MOLEX 35237-1910
P216 H03-WN19SB00000-R CONN 2.0MM 19 MA ST NAT MOLEX 35336-1910 0 0
N205 H03-WN22AI00000-R GF120-22S-LS 1.25mm 22P
N204 H03-WS4261005FN-R WIRE ASS'Y UL2547/1007#26 100MM 4P 2.0MM WHT
N202 H03-WS4265913FN-R CNT ASSY 2.0MM 4P 590MM SHIELD 26AWG UL2547 1/3
N210 H03-WS5263805NG-R WIRE ASS'Y UL2547#26(TA) 380mm 2.0mm 5P GRY
N212 H03-WS5248505CW-R WIRE ASS'Y UL1007/1533#24(TA)850mm 2.0mm 5P WHT
N208 H03-WS6265105EN-R WIRECONASY DL 2.0MM 6P 510MM UL1533 SHIELD 26 1
N211 H03-WS7260805EN-R WIRE ASS'Y UL1533/1007#26 80MM 2.0MM 7P WHT SHILED
FL1 H03-XD18BT19GNA-R 18-BT-19GINK
S1 S2 S3 S4 S5 S6 S7 S8 S9 H03-ZMB01S02200-R SPRING PLATE GND C5212 0.2T
M2 H03-ZMC12S17A00-R AC PUN SHIELD DIGITAL ET
M3 H03-ZMD12S01A00-R SHIELD IR
M4 H03-ZMD12S01B00-R SHIELD MICROPHONE
RM72 ZFNR1SENSOR-R RUBBER SENSOR
RM71 H03-ICROMN338EC-R REMOCON RECEIVER MODULE ROM-N338TEC
L251 H03-LAINB0470CR-R LF 47U0H +10% 5.8 OHM 500MI0A
L120 H03-LAINB047ACR-R LF 4U7H +10% 1.7 OHM 190.0A
AVR645
harman/kardon
107
