Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
PROCESSOR PCB
Q109 Q203 Q301 Q605 Q608
Q611 Q614 Q615 Q618 Q620
Q623 Q626 Q629
H03-TSKRA107SNI-R KRA107S SOT-23 PNP
IC20 H03-ICNJM4556B2-R IC OP AMP NJM4556AD DUAL OP-AMP DIP8
D351 D601 H03-DZGE9V120MA-R MZ0.5GE9V1-20 9.1V 20mA
IC13 IC14 IC18 IC19 IC21 IC22
IC23 IC24
H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL SOP8
IC15 H03-ICTC9162CDA-R IC CMOS DIGITAL TC9162CFG SOP28 HIGH VOLTAGE ANALOG
FUNCTION SWITCH ARRAY
IC12 H03-ICTC9163CDA-R IC CMOS DIGITAL TC9163CFG SOP28 HIGH VOLTAGE ANALOG
FUNCTION SWITCH ARRAY
IC9 H03-ICTC9273CFG-R TC9273CFG-004 SOP28 ANALOG SWITCH ARRAY ICs
IC16 IC17 H03-ICTC9482BDA-R IC CMOS DIGITAL TC9482BFG SOP28 SYSTEM ELECTRONIC VOLUME
CONTROL
Q104 Q105 Q107 Q108 Q201
Q202 Q204 Q205 Q302 Q303
Q603 Q604 Q606 Q607 Q609
Q610 Q612 Q613 Q616 Q617
Q690 Q691
H03-TRKTD1304ND-R TR-SLPSWA KTD1304 NPN 20V 300MI0A SOT-23
Q692 H03-TSKRA107SNI-R KRA107S SOT-23 PNP
Resistors
R137 R138 R157 R158 R237
R238 R239 R240 R245 R246
R307 R308 R315 R316 R324
R325 R501 R502 R507 R508
R513 R519 R539 R540 R556
R557 R558 R559 R635 R636
R651 R652 R669 R670 R685
R686 R901 R902 R903 R904
RS3AD0000NA-R RES CHIP, 0 R 1/16W +/-5%, 0603
R101 R102 R121 R122 R127
R128 R141 R142 R147 R148
R161 R162 R165 R166 R169
R170 R203 R204 R211 R212
R223 R224 R322 R323 R329
R631 R632 R649 R650 R665
R666 R687 R688 R731 R748
R771
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R191 R192 R193 R512 R520
R550 R551
RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
R103 R104 R123 R124 R129
R131 R132 R136 R143 R144
R151 R152 R153 R154 R163
R164 R167 R168 R171 R172
R183 R184 R185 R186 R189
R194 R195 R196 R197 R198
R199 R200 R207 R208 R213
R214 R227 R228 R241 R242
R303 R304 R305 R306 R311
R312 R313 R314 R518 R524
R537 R538 R548 R554 R555
R603 R604 R609 R610 R629
R630 R641 R647 R648 R657
R658 R663 R664 R677 R683
R684 R689 R690 R749 R750
RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R570 R571 RS3AD0122NA-R RMGCFMIC 1K2 OHM +5% 0603
R791 R792 RS3AD0152NA-R RES CHIP 1K5 1/16W +5% 0603
R704 R710 R716 R722 RS3AD0183NA-R RMGCFMIC 18K0 OHM +5% 0603
R553 R705 R706 R711 R717
R718
RS3AD0202NA-R RMGCFMIC 2K0 OHM +5% 0603
R611 R612 R613 R614 R691 RS3AD0221NA-R RMGCFMIC 220R0 OHM +5% 0603
R615 R616 R701 R702 R707
R708 R713 R714 R719 R720
RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R712 RS3AD0242NA-R RMGCFMIC 2K4 OHM +5% 0603
AVR645
harman/kardon
112
