Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
PROCESSOR PCB
R231 R232 RS3AD0272NA-R RMGCFMIC 2K7 OHM +5% 0603
R699 R700 RS3AD0362NA-R RMGCFMIC 3K6 OHM +5% 0603
R572 R573 RS3AD0430NA-R RES CHIP 43R0 OHM +5% 62MI5W 0603
R125 R126 R133 R134 R145
R146 R155 R156 R201 R202
R215 R216 R221 R222 R235
R236 R243 R244 R251 R252
R301 R302 R309 R310 R533
R534 R546 R547 R601 R602
R623 R624 R639 R640 R655
R656 R675 R676
RS3AD0471NA-R RMGCFMIC 470R0 OHM +5% 0603
R159 R160 R187 R188 R219
R220 R318 R319 R621 R622
R637 R638 R653 R654 R671
R672 R673 R674 R695 R696
R723 R724 R725 R726 R727
R728 R772 R773 R774 R775
R776 R777 R778 R779 R780
R781 R783
RS3AD0473NA-R RES CHIP,47K 1/16W +/-5%,0603
R703 R709 R715 R721 RS3AD0474NA-R RMGCFMIC 470K0 OHM +5% 0603
R209 R210 R229 R230 RS3AD0512NA-R RES CHIP 5K1 1/16W +5% 0603
R281 R282 R291 R292 R293
R294 R295 R296 R297 R298
R299 R300
RS3AD0823NA-R RES,CHIP 82K,1/16W,+/-5%,0603
R217 R218 R619 R620 RS3AD0100NA-R RMGCFMIC 10R0 OHM +5% 0603
R793 R794 RS3AD0123NA-R RES CHIP,12K 1/16W +/-5%,0603
R247 R248 R249 R326 R327
R328 R330 R331 R503 R504
R505 R509 R510 R511 R560
R561 R562 R643 R644 R659
R660 R679 R680 R730 R740
R743
RS3AD0102NA-R RES CHIP,1K 1/16W +/-5% ,0603
R181 R182 R233 R234 R253
R254 R535 R536 R549 R625
R626 R642 R678
RS3AD0104NA-R RES CHIP,100K 1/16W +/-5% ,0603
R515 R522 RS3AD0123NA-R RES CHIP,12K 1/16W +/-5%,0603
R591 R592 R605 R606 R627
R628
RS3AD0152NA-R RES CHIP 1K5 1/16W +5% 0603
R744 RS3AD0183NA-R RMGCFMIC 18K0 OHM +5% 0603
R552 RS3AD0202NA-R RMGCFMIC 2K0 OHM +5% 0603
R130 R135 R149 R150 R205
R206 R225 R226 R320 R321
R617 R618 R633 R634 R667
R668 R693 R694 R697 R698
R741 R742
RS3AD0222NA-R RMGCFMIC 2K2 OHM +5% 0603
R516 R517 R523 R525 RS3AD0332NA-R RMGCFMIC 3K3 OHM +5% 0603
R607 R608 RS3AD0432NA-R RMGCFMIC 4K3 OHM +5% 0603
R317 R745 RS3AD0474NA-R RMGCFMIC 470K0 OHM +5% 0603
R645 R646 R661 R681 R682 RS3AD0562NA-R RMGCFMIC 5K6 OHM +5% 0603
R190 RS3AD0753NA-R RES CHIP 75K 1/16W +-5% 0603.
R662 RS3AD0912NA-R RMGCFMIC 9K1 OHM +5% 0603
R514 R521 RS3AD0103NA-R RES CHIP,10K 1/16W +/-5% ,0603
Miscellaneous
NJ1 NJ2 NJ3 H03-SORA64105NN-R JACK RCA 6P JB060132PN
N114 N115 N313 H03-WN04AB100WH-R CONN WAFER 2.0MM 4P 35237-0410 WHT
P103 P111 H03-WN04SB00000-R CONNECT 2.0mm 4P GIL-S-4P-S2T2-EF
P112 P113 P114 P314 H03-WN04SB100WH-R CONN WAFER 2.0MM 4P 35336-0410 WHT
P100 P107 H03-WN05SB00000-R CONNECT 2.0mm 5P GIL-S-5P-S2T2-EF
N102 H03-WN06AB00001-R CNT PLUG BD'BD SOCKET 2.0mm 35237-0610
P109 H03-WN06SB00000-R CONNECT 2.0mm 6P GIL-S-6P-S2T2-EF
N104 H03-WN07AB100WH-R CONN WAFER 2.0MM 7P 35237-0710 WHT
AVR645
harman/kardon
113
