Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
VIDEO PCB
C166 CZJII0331BE-R CAP CHIP 330P0F +5% -5% 50.0V NP0 0603
C176 C503 CZKII0102BC-R CAP CHIP 1N0F +10% -10% 50.0V X7R 0603
C209 C258 C348 C515 C516 CZKII0103BC-R CAP CHIP 10N0F +10% -10% 50.0V X7R 0603
C280 C281 CZKII0221BA-R CAP CHIP 220PF 50V K SL 0603
C350 C358 CZKII0223BC-R CAP CHIP 22N0F +10% -10% 50.0V X7R 0603
C272 C274 CZKII0391BC-R CAP CHIP 390PF 50V X7R K 0603
C173 CZKII0561BC-R CAP CHIP 560P0F +10% -10% 50.0V X7R 0603
C522 CZKII0821BC-R CAP CHIP 820P0F +10% -10% 50.0V X7R 0603
C287 H03-CEHEC02275E-R CE 220UF +20% 10.0V P=5MM 85C SK 220/10V 5 X11
C242 C291 H03-CEHIC01055E-R CE 1UF +20% 50V D5XL11 P5MM 85C SK 1/50V 5 X11
C603 C174 C175 C177 C178
C179 C192 C208 C259 C260
C364 C365 C366 C438 C447
C459 C463 C500 C537
CZZFI0104BF-R CAP CHIP 100N0F +80% -20% 16.0V Y5V 0603
C540 CZJII0820BE-R CAPACITOR CERAMIC/CHIP ,82pF 50V CH J NP0 0603
C541 CZJII0121BE-R CAP CHIP 120PF 50V J NPO 0603
C542 CZDII0100BE-R CAP CHIP 10PF 50V CH D NP0 0603
C238 CZJII0470BE-R CAP CHIP 47P0F +5% -5% 50.0V NPO 0603
C602 C605 CZJII0330BE-R CAP CHIP 33P0F +5% -5% 50.0V NP0 0603
Semiconductors
Q107 Q108 Q109 H03-TRKTA1267GR-R KTA1267-GR TO-92M PNP
Q100 Q102 H03-TRKTC3199GR-R KTC3199-GR TO-92M NPN
D110 D111 D601 D602 D604
D605 D606
H03-DS05GBUSCNB-R DIODE PG05GBUSC
IC49 H03-IC74LVC254D-R IC SN74LVC257AD SOIC-16 Quadruple 2-Line To 1-Line Data
Selector/Multiplexer With 3-State Outputs
IC64 H03-ICAD1580BRT-R IC AD1580BRTZ-REEL7 1.2 V Micropower, Precision Shunt Voltage
Reference
Q121 Q122 H03-TS2N7002LND-R MOSFET N-CHANNEL 2N7002LT1G SOT-23
D130 D131 D132 D133 D135
D136 D137 D138 D139 D140
D141 D142
H03-DS05GBUSCNB-R DIODE PG05GBUSC
D100 D101 D102 D103 D104
D105 D106 D107 D108 D109
D120 D121 D122 D123 D124
D125 D607
H03-DS1S50094NB-R D-SLP 1SS355 35.0V 225MI0A
D126 D127 D128 H03-DSBAV99LTNB-R DIODE SWITCHING BAV99LT1G SOT-23
D129 H03-DSUDZ09V1NB-R D-ZENER UDZS 9.1B 9.1V 200MI0W
IC30 H03-ICKIA7806I2-R IC KIA7806AP VOLTAGE REGULATOR TO-220AB
IC66 H03-IC74CB3T3D2-R IC SN74CB3T3306DCTR SSOP-8 Dual Bus Switch Voltage Translator
IC40 H03-ICADA44106A-R IC ADA4410-6ACPZ Integrated Video Filter with Selectable Cutoff
Frequencies for GBR, HD/SD, Y, C, and CVBS
IC39 H03-ICADA44123A-R IC ADA4412-3ARQZ Integrated Triple Video Filter with Selectable Cutoff
Frequencies for RGB, HD and SD
IC29 H03-ICADV7320KS-R IC ADV7320LKSTZ 12-bit 216MHz Video Encoder with NSV and
Macrovision® Copy Protection
IC24 H03-ICADV7401EF-R ADV7401BSTZ-110 LQFP100 10-Bit, Integrated, Multiformat SDTV/HDTV
Video Decoder and RGB Graphics Digitizer
IC12 IC42 IC45 H03-ICBU4053BB4-R IC BU4053BCF SOP16 ANALOG MPX/DEMPX
IC18 IC19 IC20 IC21 IC22 H03-ICBU4094BD3-R IC CMOS BU4094BCF SOP16 8-bit compatible shift / store register
IC65 H03-ICIL11172J2-R IC VOLTAGE REGULATOR IL1117-2.5 SOT-223
IC11 H03-ICIL1117S33-R IC LOW DROP REGULATOR IL1117-3.3 3.3V SOT-223 IK
SEMICONDUCTOR
IC43 IC46 H03-ICEEP24LCD2-R 24LC08BT-I/SNG SOIC-8P MICROCHIP 8K I2C Serial EEPROM
IC60 H03-ICLM02068D2-R IC-OPERAMP NJM2068M-TE1 DUAL OP-AMP SOP8
IC25 IC26 IC33 IC34 IC35 IC36
IC37
H03-ICM1503XNRE-R MM1503XNRE SOT-26B Video Switch 75 driver Y/C mix
IC32 H03-ICMM1511XDL-R IC-VIDEO SW MM1511XNRE SOT-26B Video Switch 75 driver Y/C mix
IC13 IC14 IC15 H03-ICNJM2296D3-R IC-LINEAR NJM2296M-TE1 5-INPUT 3-OUTPUT VIDEO SWITCH
IC38 H03-ICNJM2586MN-R IC VIDEO AMP NJM2586M-TE1 DMP24 WIDE BAND 3-INPUT 1-OUTPUT 3-
CIRCUIT VIDEO AMPLIFIER
IC55 H03-ICSII903144-R IC HDMI RECEIVER SIL9031CTU TQFP144 Multi-Channel Audio Receiver
Chipset
IC54 H03-ICSIL903080-R HDMI TRANSMITTER SII9030CTU TQFP80
AVR645
harman/kardon
119
