Harman Kardon AVR 645 Service Manual

Ref. Designator Part Number
Description
MECHANICAL ASSEMBLY
H03-ZPD0315GAMW-R VOLUMN KNOB
H03-ZPD0316GASG-R COVER KNOB
H03-ZPD0317GACR-R CAP KNOB VOLUMN
H03-ZPD2919GABT-R WINDOW DISPLAY AVR645+BADGE NAME AVR645
H03-ZVC11DWT100-R TAPE DOOR
H03-ZVC11DWT200-R TAPE PANEL
H03-ZVC11GEAR01-R DAMPER GEAR DP120
H03-ZVC11TUNE01-R TUNER MODULE KST-MB011MW0-81 US US
H03-ZVD01TUNE00-R TUNER MODULE KST-MB114MW1-81 OEM EU EU
H03-ZVJF0925S00-R DC FAN JF0925S1M-003C651R 12V 92x92x25mm
ZFD122062SB-R RUBBER TOP AVR635
ZFD122072SB-R RUBBER TOP AVR635
ZFNR13830SB-R RUBBER SIDE
ZFNR19720SB-R RUBBER FOOT 19.7X19.7X2T BK
ZMC12S13AYE-R STANDOFF HEX M4X0.7 6X31.9H
ZMC12S14AYE-R STANDOFF HEX M4X0.7 6X61.9H
ZNSSM4045HZ-R NUT M4 HEXAGON CIRCULAR EXTERNAL
ZPC1002GAGY-R DOOR AVR
ZPC1003GAGY-R BUTTON POWER
ZPC1005GAGY-R BUTTON 8 KEY
ZPC1006GAWH-R BUTTON STANDBY
ZPC1007GAMW-R INDICATOR STAND-BY
ZPC1017GABK-R HOLDER VFD AVR
ZPC1102GAMW-R INDICATOR VIDEO
ZPC1103GAGY-R FOOT 50MM 15.8MM
ZPD2701GAGY-R PANEL FRONT AVR745
ZSMCM4008BY-R SCREW BM 4X8
ZSMCM4010BB-R SCREW BM 4X10
ZSMPM3006LB-R SCREW.M.S.M3X6 P/HD BLACK
ZSTBM3008BY-R SCREW ST BH 3X8
ZSTBM3010BB-R SCREW ST BH 3X10
ZSTBM3012BY-R SCREW ST BH 3X12 PIVOT
ZSTGM3010BB-R SCREW ST BH 3X10 GROUND
ZSTWM3006BB-R SCREW ST WPH 3X6
ZSTWM3008BY-R SCREW ST WPH 3X8
ZSTWM3A08BY-R SCREW ST W7.5PH 3X8
ZSTWM4008BC-R SCREW ST WPH 4X8 SILVER CHROM
ZUC1201AABK-R SPONGE 30X30X10T BK
ZWF793008PO-R WASHER FIBER 3 0.8T
ZWM623108SZ-R WASHER SPRING 3
ZWM763109SZ-R AC SPRING WASHER RT2250(PAV5005)
ZWM803305PZ-R WASHER PLAIN 3
ZWMC04810PZ-R WASHER PLAIN 4
H03-WF16S0700ST-R WIRE FFC CABLE DHCDT-16/70-P1.25-ST(5/5,10/10)
H03-WF14S1705ST-R WIRE FFC CABLE DHCDT-14/170-P1.25-ST(5/5,10/10)
H03-WG09SB82000-R WIRE ASS'Y UL1007#26(TA) 200mm 2.0mm 9P WHT
H03-FBD0480BR00-R FCORE CLAMP FILTER LF80BR W5 SRH 16X28X9
H03-ZUD0301ABBK-R SPONGE-UL 30X30X12T BK
H03-ZMD27S07A00-R SHIELD AL
ZSTBM3014BY-R SCREW ST BH 3X14 PIVOT
ZFNR19730SB-R RUBBER FOOT 19.7X19.7X3.0T BK
TUNER MODULE USA ONLY H03-ZVC11TUNE01-R TUNER MODULE KST-MB011MW0-81 USA ONLY
TUNER MODULE EUROPE H03-ZVD01TUNE00-R TUNER MODULE KST-MB114MW1-81 OEM EUROPE ONLY
AVR645
harman/kardon
123
