Harman Kardon AVR 645 Service Manual

52 H03-TXPWMEI95B0 PWR TRANSFORMER AVR645 MAIN 120V 60Hz 1
52 ---
H03-TXPWMEI93B0 PWR TRANSFORMER AVR645 MAIN 230V 50Hz
1
53 H03-ZMC12HS0100 AC HEATSINK 17x15x30 AVR--ME 1
54 H03-ZMC11HS0400 HEATSINK DIODE 47x26x12 AVR 1
55 H03-SOXA27014NN CON MAINS INLETAIC A/C INLET7014-NGP 1
56 H03-ZMC12S19A00 BKT AC INLET 2
57 H03-SOXA2202DNN A202D0031P 2P 1
57 --- H03-SOXA0302DNN-R-3 A302D0061P AC Out Let (1P) 1
58 H03-ZMD27S06A00 BKT VIDEO 1
59 H03-ZMD27S04A00 BKT FRAME GUIDE AVR 1
60 H03-ZMD27HS0100 H/SINK AMP AVR 1
61 H03-ZMC12S09A00 BKT HEATSINK 5
62 H03-SOPA8SH0612 JACK SPEAKER 6P SH0612707P GN BN TA 1
63 H03-ZMD27HS0300 HEATSINK AMP SMALL 1
64 H03-SORA10003GN JACK RCA 1P JE010003SG GND YELLOW GOCD CO 1
65 SOPA96063NN JACK D-SUB 9P 87204-6063 W/DUST COVER BK 1
66 H03-SOJW2350SNN-R-7 JACK PHONE 3.6 EP-1401A 1P BK 5
67 H03-ZMC12S16A00 BKT GROUND 1
68 H03-ZMC11S10A00 BKT FAN REAR AVR 1
69 H03-SOYKF457009 JACKI HDMI YKF45-7009 JALCO 3
70 H03-SOR12BJ12NN JACK RCA 12P BJ120154JN R4 BU4 G4 1
71 H03-SORA60031YN JACK RCA+S-VIDEO 6P C8030031YN 2
72 H03-ZMD29S02A00 PANEL REAR AVR645US 1
72 --- H03-ZMD30S02A00 PANEL REAR AVR645EU 1
73 H03-SOUSB45810B JACK R41-5810B (Mitsumi) XM/DT connector 1
74 H03-SOUSB5005K0 AU6-EC-005K0 1
75 H03-SOTX220750N JACK RCA+OPTICAL TX YKC22-0750N 1
76 H03-SORX220751N JACK RCA+OPTICAL RX YKC22-0751N 1
77 H03-SORA40RSANN JACK RCA 4P JB040131ZN GN,BN,PP,TA 1
78 H03-SORA40RSCNN JACK RCA 4P JB040131QN WH,BU,RD,GY 1
79 H03-ZMD27S05A00 BKT IPOD 1
80 H03-SO1R018H91E DA1R018H91E 1
81 H03-SORA1J440GE JACK RCA 1P PPJ-440FEG PP GOLD COLOR 1
82 H03-SORA64105NN JACK RCA 6P JB060132PN WWWRRR 3
83 H03-ZVC11TUNE01 TUNER MODULE KST-MB011MW0-81 US 1
83 H03-ZVD01TUNE00
TUNER MODULE KST-MB114MW1-81 OEM EU
1
84 H03-ZMC11S04B00 BKT FRAME-GUIDE 1
85 ZMC12S13AYE STANDOFF HEX M4x0.7 6x31.9H 2
86 SO0A18P8CNN
JACK-TELE SNAPG-IN GDLDEN TELECOM 1-8P8C 8T BK 1
87 H03-SOPA81900NN
CONN-SPE TERMINAL SPKR 8P SH081136JP FE 19MM 8 - 00
1
88 ZMC12S14AYE STANDOFF HEX M4X0.7 6X61.9H 3
89 H03-ZMD27HS0400
H/SINK REG. TR AVR
1
90 ZFNR13830SB RUBER SIDE 6
91 H03-ZMC12S07A00 COVER BOTTOM 1
92 ZUC1201AABK SPONGE 30X30X10T BK 3
93 H03-ZMD2701ZANI
BRACKET POSISTOR,METAL,AVR
2
94 H03-ZMD12S01C00 SHIELD DSP AVR 1
95 --- BKT HDMI AVR 1
96 ---
SPEAKER TERMINAL KNOB CORK B3M790BO
14
97 H03-ZMD27S07A00 SHIELD AL 1
98 H03-ZUD0301ABBK SPONGE-UL 30X30X12T BK 1
99 H03-ZMD27S09A00 BRACKET BKT XM 1
SW H03-SWC2A112FS1 SWITCH VERTICAL SKQNADD010 20
---
N1
ZNSSM4045HZ NUT M4 HEXAGON CIRCULAR EXTERNAL 4
N2
ZNSSM3023HZ NUT M3 ZN PLATED 1
S1
ZSTBM3010BB SCREW ST BH 3X10 64
S2
ZSTWM3008BY SCREW ST WPH 3X8 45
S3
ZSMCM4010BB SCREW BM 4X10 4
S4
ZSTWM4008BC SCREW ST WPH 4X8 SILVER CHROM 14
AVR645
harman/kardon
31
