RF-5800H 125-WATT COMMUNICATION SYSTEM
INSTALLATION
2-19/2-20
Figure 2-9. RF-5800H 125-Watt Transit
Case System Installation
Configuration
5800H-125-129A
SLIDE POWER SUPPLY
RF-5051PS INTO TRANSIT
CASE MOUNT
SLIDE RF-5800H-MP INTO
TRANSIT CASE MOUNT
PLACE TRANSIT CASES INTO
POSITION
CONNECT CABLES (SEE FIGURE 2-11).
1
3
4
5
6
8
SLIDE RF-5832H-PA INTO
TRANSIT CASE MOUNT
2
TIGHTEN
WING NUT
TIGHTEN
WING NUT
7
TIGHTEN
WING NUT
