Harris RF-5800H-MP - 7.3 LRU DIAGRAMS

RF-5800H 125-WATT COMMUNICATION SYSTEM
PARTS LIST
7-4
Table 7-11. Available Option Cables (Purchased Separately)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– Cable Assembly, PA-Coupler (Control) 10181-9823 – – 7-13
– Cable Assembly, PA-Coupler (RF) 10181-9824 – – 7-12
– Cable Assembly, KY-99A Audio/Black Data 10535-0701-A004 – – 7-14
– Cable Assembly, RS-232 Black Data to
Encryption Device
10535-0702-A1 – – 7-15
– Y-Cable Assembly, ASCII Remote and PA
Control
10535-0730 – – 7-16
– Cable Assembly, KG-84C Black Data 10535-0750 – – 7-17
– Cable Assembly, ASCII Remote Control
Rear D-Connector
10535-0760 – – 7-18
– Cable Assembly, Sync/Async RS-232 DTE
Data
10535-0770 – – 7-19
– Cable Assembly, Synchronous RS-232 DTE
Data (DB-25)
10535-0780 – – 7-20
– Cable Assembly, Asynchronous Data (PPP) 10535-0775 – – 7-21
7.3 LRU DIAGRAMS
Figures 7-1 through 7-7 show the LRUs within each system configuration identified in Tables 7-1 through 7-9.
Optional cables for the system are listed in Tables 7-10 and 7-11 and shown in Figures 7-8 through 7-25.
