RF-5800H 125-WATT COMMUNICATION SYSTEM
PARTS LIST
7-3
Table 7-7. RF-5211VSM Ancillary Kit Parts List (10372-0875-01)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– FW SS .281X.625 MS15795-810 3 –
– FW SS .344X.688 MS15795-812 4 –
– Bolt Hex HD 1/4-20X1 MS35307-308 1 –
– Bolt Hex HD 5/16-18X7/8 MS35307-333 4 –
– LW SPLT SS MS35338-139 2 –
– LW SPLT SS MS35338-140 4 –
– Lockwasher .250 MS45904-68 1 –
– Nut Hex 1/4-20 MS51971-1 2 –
– Nut No. 5/16-18 MS51971-2 4 –
– O&I Drawing 10372-0876 1 –
– Ground Strap 7147-1167-3 1 7-25
Table 7-8. RF-5051PS Power Supply Assembly Parts List (10299-5051-03)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– – RF-5051PS Chassis Assembly 10299-5051 2 7-2
– – RF-5051PS Ancillary Kit 10181-9010 1 –
Table 7-9. RF-5051PS Ancillary Kit Parts List (10181-9010)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– – Fuse, 1/8A, SB F03-0002-005 5 –
– – Fuse, 15A, Ceramic, SB F03-0003-021 5 –
– – AC Power Cable 10181-9831-009 1 7-11
– – Ground Strap 7147-1167-3 1 7-25
Table 7-10. Available Power Cables (Purchased Separately)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– Cable Assembly, AC Power 10181-9831-XXX – – 7-11
