RF-5800H 125-WATT COMMUNICATION SYSTEM
TROUBLESHOOTING
6-10
6.3 TROUBLESHOOTING SUPPORT DATA
6.3.1 Protective Device Index
Table 6-4 is the protective device index. The RF-5832H-PA is protected by one 30-ampere circuit breaker. The
circuit breaker, CB1, is accessible at the front panel of the power amplifier. The circuit breaker protects both the
power amplifier and RF-5800H-MP.
Table 6-4. Protective Device Index
Rating
Reference
Designation
Panel Marking
or ID
Volts Amperes
Circuit
Protected
Figure
Ref.
CB1 CB1 65 Vdc 30 A RF-5832H-PA/
RF-5800H-MP
1-3
6.3.2 Troubleshooting Index
Table 6-5 is the troubleshooting index for the RF-5800H 125-Watt Communication System. Use the
troubleshooting index if the actions in the non-BIT troubleshooting (Paragraph 6.2.3) or the BIT troubleshooting
(Paragraph 6.2.4) procedures do not correct the problem. The first column of Table 6-5 references the functional
areas. The second column references the Figure for each functional area. The third column references the text
description for each functional area. Analyze the information for each functional area, and determine which units
and cables affect each functional area in an attempt to isolate the problem to an LRU.
The information contained in this manual complies with the requirements specified for Level II maintenance.
Table 6-5. Troubleshooting Index
Functional Area
Signal Path
Diagram
Functional
Description
Paragraph
RF/Audio Signal Path 4-1 4.2.1
Control Path 4-1 4.2.2
Power Distribution 4-2 4.2.3
To Next Page
