RF-5800H 125-WATT COMMUNICATION SYSTEM
PARTS LIST
7-2
Table 7-3. RF-5800H 125-Watt Transit Case System LRUs
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– RF-5832H-PA 125-Watt Power Amplifier RF-5832H-PA001 1 7-1
RF-5051PS-125 Power Supply 10299-5051-03 1 7-2
Speaker, Vehicular Mount 10181-5180-01 1
Coaxial Cable Assembly, R/T-PA (RF) 10181-9821-015 1 7-8
Cable Assembly, AC PWR 10181-9831-009 1 7-11
DC Power Cable 10181-9833-004 1 7-22
Cable Assembly, Ground Strap 10400-1136-A006 1 7-25
Cable Assembly, Ground Strap 10400-1136-A06 1 7-25
Cable Assembly, Speaker Power 10535-0706-A015 1 7-23
Cable Assembly, Audio Speaker 10535-0707-A003 1 7-24
Cable Assembly, R/T-PA (Control) 10535-0720-A015 1 7-10
RF-5800H-125W Transit Case, R/T 11040-1100-01 1 7-7
RF-5800H-125W Transit Case, PA/PS 10400-0561-01 1 7-7
Table 7-4. RF-5071VSM Shock Mount Assembly Parts List (10181-5071)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– RF-5071VSM Shock Mount, Single 10181-9800 1 7-3
– RF-5071VSM Ancillary Kit 10181-9030 1 –
Table 7-5. RF-5071VSM Ancillary Kit Parts List (10181-9030)
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– Bolt, Hex, 3/8 MS35307-358 4 –
– LW SS INT.#3/8 MS35333-76 8 –
– Nut, 9/16 Hex MS51971-3 4 –
Table 7-6. RF-5211VSM Shock Mount Assembly Parts List
Ref. Des.
Item Name
Part
Number
Quantity
Figure
Number
– RF-5211VSM Chassis Assembly 10372-0870-01 1 7-4
– RF-5211VSM Ancillary Kit 10372-0875-01 1 –
