RF-5800H 125-WATT COMMUNICATION SYSTEM
APPENDIX A
A-1
APPENDIX A
A.1 TECHNICAL SPECIFICATIONS
Table A-1 provides RF-5832H-PA specifications. Tables A-2, A-3, and A-4 provide specifications for the
RF-5051PS, RF-382A, and the RF-5056PS DC/DC Power Converter.
Table A-1. RF-5832H-PA Specifications
Function
Specification
GENERAL
Frequency Range 1.6 MHz to 29.99999 MHz
RF Input/Output Impedance 50 ohm nominal, unbalanced
Power Input +28.0 Vdc (per MIL-STD-1275) at 30 A maximum
Voltage +22.5 Vdc to +30 Vdc
Temperature Range –40° C to +70° C
Environmental MIL-STD-810E
Heat Dissipation to Air 395 W
Cooling Air Flow Required 106 Cubic Feet per Minute (CFM)
Relative Humidity 0 to 95%
Leakage MIL-STD-810E (1 meter depth)
Size 7.5W x 10.0D x 5.5H inches (19.0W x 25.5D x 14.0H cm.)
Weight 12.8lbs. (5.8 kg)
POWER AMPLIFIER
Power Output 125 watts PEP/Average into a 50 ohm load
RF Drive Requirements +20 dBm (100 mW)
Intermodulation Distortion –30dB below PEP
Harmonic Output –40 dB
Table A-2. RF-5051PS Specifications
Function
Specification
GENERAL
Input Voltage 90–150 V
rms
Single Phase (120 V nominal tap selected)
180–300 V
rms
Single Phase (240 V nominal tap selected)
Note: Tap selection is automatic.
Line Frequency 47 – 440 Hz
Power Consumption 1010 Watts/1450 VA at full load
Output 28 Vdc at 30 A (+26.4 Vdc nominal)
Load Regulation –10 mV/ampere
Line Regulation 30 mV maximum output variation for 120/240 V
± 20% input variation
Size 7.5 W x 13.5 D x 5.5 H (inches)
19.0 W x 34.3 D x 14.0 H (centimeters)
Weight 17.3 lbs. (7.86 kg)
