RF-5800H 125-WATT COMMUNICATION SYSTEM
GENERAL INFORMATION
1-4
1.4 WARRANTY
Harris Corporation guarantees that if the equipment fails from normal use within one year from the date of
shipment due to a defect in workmanship or materials, Harris will repair or replace the equipment at no charge.
Repairs made by Harris to the equipment under this warranty are warranted to be free from defects in material and
workmanship for 60 days from the date of repair.
For information on how to process a claim under this warranty, and on what is not covered by this warranty, refer
to the warranty information printed on the inside front cover of this manual.
1.5 GENERAL SYSTEM DESCRIPTION
Table 1-1 identifies the RF-5800H 125-Watt Communication System configurations. Paragraphs 1.5.1 through
1.5.3 describes the configuration.
Table 1-1. RF-5800H 125-Watt Configurations
Description
125-Watt Vehicular System
125-Watt Base Station System
125-Watt Transit Case System
1.5.1 RF-5800H 125-Watt Vehicular System
Figure 1-3 shows the relationship of the units contained in the RF-5800H 125-Watt Vehicular System and Figure
1-4 is the family tree. This system contains an RF-5832H-PA 125-Watt Power Amplifier (herein after referred to
as RF-5832H-PA), interconnect cables, ground strap, and two shock mounts. The RF-5211VSM Vehicular Shock
Mount (herein after referred to as RF-5211VSM) is used with the RF-5800H-MP Manpack Radio (herein after
referred to as RF-5800H-MP) and the RF-5071VSM Vehicular Shock Mount (herein after referred to as
RF-5071VSM) is used with the RF-5832H-PA. The RF-5800H-MP and the optional RF-382A Automatic
Antenna Coupler (herein after referred to as RF-382A) are ordered separately.
1.5.2 RF-5800H 125-Watt Base Station System
Figure 1-5 shows the relationship of the units contained in the RF-5800H 125-Watt Base Station System. Figure
1-6 is the family tree. This system contains an RF-5832H-PA, an RF-5051PS Power Supply (herein after referred
to as RF-5051PS), and an external speaker. The RF-5800H-MP and RF-382A are ordered separately.
1.5.3 RF-5800H 125-Watt Transit Case System
Figure 1-7 shows the relationship of the units contained in the typical configuration of the RF-5800H 125-Watt
Transit Case System. Figure 1-8 is the family tree. This system consists of a transit case containing an
RF-5832H-PA, an RF-5051PS, and a shock mount for the RF-5832H-PA. A mounting tray for an RF-5800H-MP
and an external speaker are mounted in a separate transit case. The RF-5800H-MP and RF-382A are ordered
separately.
