RF-5800H 125-WATT COMMUNICATION SYSTEM
PARTS LIST
7-1
CHAPTER 7
PARTS LIST
7.1 INTRODUCTION
This chapter contains radio system parts list information for the RF-5800H 125-Watt Communication System.
This information can be used to identify units within each radio system configuration, and to place orders for
those units. This chapter is organized as follows:
• Paragraph 7.2 – LRUs
• Paragraph 7.3 – LRU Diagrams
7.2 LRUs
Tables 7-1 through 7-9 list the LRUs that comprise the RF-5800H 125-Watt Communication System. Tables 7-10
and 7-11 list the optional cables available. Quantity, part number, and figure number references, including those in
Chapter 1, are also provided.
Table 7-1. RF-5800H 125-Watt Vehicular System LRUs
Ref. Des. Item Name
Part
Number
Quantity
Figure
Number
– RF-5832H-PA 125-Watt Power Amplifier RF-5832H-PA001 1 7-1
– Vehicular Shock Mount RF-5071VSM 1 7-3
– Vehicular Shock Mount RF-5211VSM 1 7-4
– Optional Vehicular Shock Mount RF-5211-01VSM Optional 7-5
– Coaxial Cable Assembly, R/T-PA (RF) 10181-9821-020 1 7-8
– Cable Assembly, DC Power 10181-9826-020 1 7-9
– Cable Assembly, R/T-PA (Control) 10535-0720-A020 1 7-10
– Ground Strap, Braided 7147-1167-3 1 7-25
Table 7-2. RF-5800H 125-Watt Base Station System LRUs
Ref. Des.
Item Name Part Number Quantity
Figure
Number
– RF-5832H-PA 125-Watt Power Amplifier RF-5832H-PA001 1 7-1
RF-5051PS-125 Power Supply 10299-5051-03 1 7-2
Speaker, Vehicular Mount 10181-5180-01 1
Coaxial Cable Assembly, R/T-PA (RF) 10181-9821-015 1 7-8
Cable Assembly, AC PWR 10181-9831-009 1 7-11
DC Power Cable 10181-9833-004 1 7-22
Cable Assembly, Ground Strap 10400-1136-A006 1 7-25
Cable Assembly, Ground Strap 10400-1136-A06 1 7-25
Cable Assembly, Speaker Power 10535-0706-A015 1 7-23
Cable Assembly, Speaker 10535-0707-A003 1 7-24
Cable Assembly, R/T-PA (Control) 10535-0720-A015 1 7-10
RF-5800H-125W Base Station Mount 10558-2000-02 1 7-6
