RF-5800H 125-WATT COMMUNICATION SYSTEM
FUNCTIONAL DESCRIPTION
4-3
Figure 4-1. RF-5800H 125-Watt Communication System RF/Audio and Control Paths
RF SIGNALS
AUDIO SIGNALS
CONTROL SIGNALS
KEY
RF-5800H-MP
RF-5832H-PA
J1
J6 J7
J12
J9
J8
J11
5800H–125VEH4A
RF-382A
(OPTIONAL)
J2
J1
HF
ANTENNA
NOTE:
A BROADBAND 50 W HF ANTENNA
CAN BE CONNECTED DIRECTLY
TO J11.
HANDSET
(H-250/U)
(10075-1399)
SPEAKER
(OPTIONAL)
