RF-5800H 125-WATT COMMUNICATION SYSTEM
TROUBLESHOOTING
6-8
TAP-1: NO POWER UP (VEHICULAR)
RF-5800H 125-Watt Vehicular System does not power up.
INITIAL CHECKS
S Make sure all cables are connected.
S Make sure all units are properly seated.
S Make sure all connections are tight and there are no
broken connections.
PROCEDURE
Check fuse in vehicle circuit supplying radio system.
Is fuse good?
YN
Remove and replace fuse.
Check CB1 on RF-5832H-PA.
Is CB1 closed?
YN
Reset circuit breaker and retest system.
Does CB1 stay closed?
YN
Remove and replace RF-5832H-PA and
retest system.
Does CB1 stay closed?
YN
Reinstall old RF-5832H-PA.
Remove and replace
RF-5800H-MP and retest
system.
Does CB1 stay closed?
YN
Refer to
troubleshooting index
to identify faulty
system cable.
Return system to operational
readiness.
Return system to operational readiness.
AB
AB
Does system power up?
YN
Remove and replace RF-5800H-MP.
Return system to operational readiness.
Return system to operational readiness.
Remove and replace RF-5832H-PA.
Does system power up?
YN
Remove and replace RF-5800H-MP. Return system
to operational readiness.
Return system to operational readiness.
