32
Display mode button 5
Steps through the various view modes for the preview im-
age: standard, histogram overlay, image details, screen off
and full-screen.
Menu / (Menu Exit) button 4
Opens and closes the menu system. Also used for various
other tasks (Exit button, for example) as you issue commands
within the menu system indicated by a description beside the but-
ton on the preview screen.
Preview screen 3
Displays preview images and the menu system even in bright light
and from acute angles.
ON/OFFbutton 2
Powers the CFV.
Lock safety button 1
Prevents unintentional movement of back lock.
Parts, components & control panel buttons
The interface buttons are used for browsing images and navigating the menu system to make settings. Two of the buttons, located at
the bottom-right and -left of the screen, are given an on-screen label that changes according to the current context. For example, the
Approval button sets the approval rating when browsing images, but becomes an OK button to confirm settings.
1
2
3
4
5
6
7
8
9
10
11
16
17
18
19
20
21
22
23
12
13
14
15
