Hatz 1B30E - Page 22

Technical data 1B30E, 1B50E / 02 - Rev. 01
22
HATZ
Manual
Maximum permissible inclination during continuous operation *
1B30E and 1B50E without additional oil pan
35°
25°
35°
35°
1B30E with additional oil pan and a maximum speed of up to 2500rpm
1B50E with additional oil pan at all speeds
35°
25°
35°
35°
1B30E with additional oil pan and a maximum speed above 2500rpm
15°
15°
15°
15°
*
Exceeding these limit values causes engine damage.
