Engine overview 1B30E, 1B50E / 02 - Rev. 01
28
HATZ
Manual
14 Oil temperature sensor
15 Crankshaft – power take-off (pto)
16 Oil pressure switch
17 Exhaust manifold with exhaust screen (exhaust outlet: lateral)
18 Temperature switch
19 Air filter maintenance indicator (option)
20 Cylinder head cover
21 Type plate
Exhaust side (standard model)
1 Exhaust manifold with exhaust screen (exhaust outlet: top)
2 Silencer with contact protection
3 Engine control unit
4 Starter
5 Voltage controller
6 Engine bracket
7 Water separator
8 Intake opening for cooling and combustion air
9 Fuel prefilter (in tank)
