Operation and use 1B30E, 1B50E / 02 - Rev. 01
46
HATZ
Manual
CAUTION
Danger of later engine damage.
▪ Operating the engine with an oil level below the min. mark
or above the max. mark can lead to engine damage.
▪ When checking the oil level, the engine must be horizontal
and have been switched off for a few minutes.
Overview
1 Dipstick
2 Oil refilling container
Procedure
Step Activity
1 Switch off the engine and wait several minutes for the engine oil
to collect in the crankcase. Engine must be level.
2 Remove contamination on the engine in the area of the dipstick.
3 Unscrew the dipstick and clean it.
4 Reinsert the dipstick and screw it tight.
5 Unscrew the dipstick and check the oil level.
6 If the oil level is close to the min. mark, add engine oil to the
max. mark.
7 Reinsert the dipstick and screw it tight.
