Operation and use 1B30E, 1B50E / 02 - Rev. 01
50
HATZ
Manual
Overview
Water in the fuel tank collects at the lowest point of the fuel tank in the water
separator.
Standard Model with window
1 Drain screw, hex (standard)
2 Window (additional equipment)
3 Drain screw (manually operated)
Procedure
Step Activity
1 Model with window:
Check the window(2) for water content.
Collected water can be clearly identified by the noticeable sepa-
rating line between the water and the diesel fuel above it.
2 Place a suitable container under the drain screw(1)or(3).
NOTE: In inaccessible locations, an extension hose can be
mounted on the drain screw(3).
3 Open the drain screw(1)or(3) and drain the water into the con-
tainer.
4 When fuel emerges, close the drain screw.
5 Dispose of the water/fuel mixture in accordance with the local
environmental regulations.
