1B30E, 1B50E / 02 - Rev. 01 Maintenance
HATZ
59Manual
Draining the engine oil
Overview
Standard model With additional oil pan
1 Oil drain screw (side)
2 Oil drain screw (front)
3 Seal ring
Procedure
Step Activity
1 Keep a container ready for collecting the used oil. The container
must be large enough to hold the entire amount of engine oil.
For the engine oil capacity, see chapter 4.1 Engine information
and filling quantities, page 21.
2 Depending on accessibility, the engine oil can be drained at oil
drain screw(1)or(2).
Unscrew the oil drain screw and drain the used oil entirely.
3 Screw in the cleaned oil drain screw with the new sealing ring
and tighten. Tightening torque: 50 Nm.
