Hawk Gladiator User Manual

34
Admittance Smart Switch Series
Manual
Rev 1.2, June 2008
35
PART NUMBERING
SMART PROBE VERSION
AS2100 Gladiator Admittance Switch - Smart Probe
Power Supply
B 24 Vdc standard (7-30Vdc)
U Universal AC power supply (80-260Vac input) and 7-30Vdc
Output Options
S Switch only, 1 level relay, Modbus
Z Special Request
Housing
S Standard Powder Coated, Diecast with glass lid
C Corrosion Resistant, stainless steel housing
Guard Length (excludes 100mm ground length)
1 150 mm (5.9”)
Z Special Request
Temperature
1 Maximum 80ºC (176ºF)
2 Maximum 150ºC (302ºF) Temperature extension length 150 mm (5.9”), Teon
3 Maximum 250ºC (482ºF) Temperature extension length 250 mm (9.8”), Teon
4 Maximum 450ºC (842ºF) Temperature extension length 350 mm (13.7”), Ceramic
Probe Type
1 Standard rod (non-insulated)
2 Insulated rod
3 Cable (non-insulated)
Mounting
TN07 3/4” NPT Thread (not available with high temp ceramic version)
TB07 3/4” BSP Thread (not available with high temp ceramic version)
TN10 1” NPT Thread (not available with high temp ceramic version)
TB10 1” BSP Thread (not available with high temp ceramic version)
TN15 1.5” NPT Thread
TB15 1.5” BSP Thread
TZ Special Thread Request
FA2 2” Flange ANSI (Class 150)
FD2 2” Flange DIN 50 (PN 40)
FJ2 2” Flange JIS (10K)
FZ Special ange request
Approvals
A22 ATEX 22 (Pending)
X Standard CE Approved
(P)Probe (C)Cable Length
P30 - 300mm (11.8”)
P50 - 500mm (19.6”)
P100 - 1000mm (39.3”)
C100 - 1000mm (39.3”)
C200 - 2000mm (78.7”)
C300 - 3000mm (118.1”)
For longer consult factory
AS2100 B S S 1 1 1 TB15 X P30

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
