Hawk Gladiator User Manual

28
29
Sultan 234 Series
Admittance Smart Switch Series
Manual
Rev 1.2, June 2008
Normal
0.0%
Press
Press
Press
Min: 0.0%
0.0%
Press
Operation Mode
Current temperature inside probe housing (ºCelsius).
Programmed switch On / switch Off delay (seconds).
Minimum captured Sensor Value % since last history
log reset, or last Cal Mounting operation.
Normal / Comms Retry / Fail
Sensor Value
0.0%
Temp: 23.3C
0.0%
Delay: 0.1S
0.0%
(Continued next page)
FLOW CHART
DIAGNOSTIC DISPLAYS (Remote type only)
The diagnostic displays appear on the top line of the LCD, after pressing the Up or
Down push button when the Gladiator switch is in its normal running mode.
The diagnostics provide the user with valuable performance feedback on how the
instrument is performing whilst in operation.
The measured reading Sensor Value (%) continues to be displayed on the second
line of the LCD during diagnostic viewing on the top line. Ouput relays will continue to
operate during diagnostic viewing.

Hawk Gladiator Specifications

Power

operating voltage	12-30VDC, 90-260VAC, 36-60VDC
power consumption	<0.8W @ 24VDC, <5VA @ 240Vac, <3VA @ 115Vac

Operating Environment

maximum operating pressure	2 BAR
operating temperature for remote electronics	-40°C (-40°F) to 80°C (176°F)
operating temperature for remote sensors	-20°C (-4°F) to 80°C (176°F)
enclosure sealing for remote electronics	IP67 (NEMA 4x)
enclosure sealing for remote sensors	IP68

Weight and Dimensions

transducer to amplifier separation	Up to 500m (1640ft)
typical weight for 15kHz transducer	8 kg
typical weight for remote amplifier	1 kg
