T210
ELECTRICAL CONNECTION
10
5 ELECTRICAL CONNECTION
5.1 General information
For the electrical connection between the torque transducer and measuring amplifier we
recommend using shielded, low-capacitance measuring cables.
With extension cables, make sure that there is a proper connection with minimum contact
resistance and good insulation. All plug connections or swivel nuts must be tightened
firmly.
Do not route the measurement cables parallel to power lines and control circuits. If this
cannot be avoided (in cable pits, for example), maintain a minimum distance of 50 cm
and also draw the measuring cable into a steel tube.
Avoid transformers, motors, contactors, thyristor controls and similar stray-field sources.
5.2 Connector plug
The transducer is equipped with a permanently mounted housing connector.
It can be connected to the corresponding measurement electronics via the transducer
connection cable (available as an accessory). Please refer to the following table for the
pin assignment of the transducer connection cables.
