DIMENSIONS
9 DIMENSIONS
Size 1 – 0.5 N·m, 1 N·m, 2 N·m
Dimensions in mm
Measuring side labeling M16 connector plug, type Binder 680
Status LED
40
2
2
11 11
22
62±0.1
95
14.5
14.5
4xM3 / 5 deep
4x90°=360°
45°
14
28
54
65.5
28±0.1
M3
6mm
Ø8 g6
Ø6 g6
Ø32
±0,1
Ø27
-0.1
Ø27
-0.1
