T210
DIMENSIONS
20
Size 2 – 5 N·m, 10 N·m, 20 N·m
Dimensions in mm
M16 connector plug, type Binder 680
Measuring side labeling
Status LED
60
32
145
30
30
79±0.1
9.5
2
2
9.5
4xM3 / 6 deep
42±0.1
45°
21
42
68
79.5
M3 / 6 deep
On measuring side
Ø38
-0.1
Ø16 g6 Ø16 g6
Ø38
-0.1
4x90°=360°
Ø46±0
.1
Ø38
-0.1
Ø16 g6
4x90°=360°
Ø46±0
.1
