HBK T210 - Page 23

21
T210
DIMENSIONS
Size 3 – 50 N·m, 100 N·m, 200 N·m
Dimensions in mm
M16 connector plug
Status LED
3
3
15 1542
40
72±0.1
45
45
170
45°
56±0.1
93.6
56
28
M4
6mm
Measuring side
labeling
Ø54
-0.1
Ø26 g6
4x90°=360°
Ø65±0
.1
Ø54
-0.1
Ø26 g6
4xM4 / 5 deep
Type Binder 680
