T210
SPECIFICATIONS
22
10 SPECIFICATIONS
Type T210
Accuracy class 0.1
Size BG1 BG2 BG3
Nominal (rated) torque M
nom
Nm 0.5 1 2 5 10 20 50 100 200
Maximum speed n
max
rpm 30,000 20,000 14,000
Torque measuring system
Linearity deviation including hysteresis
relating to the rated output (nominal)
% ≤±0.05
Relative standard deviation of repeatability,
as per DIN1319 relating to the variation of
the output signal
% ≤±0.05
Temperature effect per 10K in the nominal
(rated) temperature range
on the output signal, relating to the actual
value of the signal spread
Frequency output
Voltage output
%
%
≤±0.1
≤±0.1
on the zero signal relating to the rated output
(nominal)
Frequency output
Voltage output
%
%
≤±0.1
≤±0.1
Nominal (rated) sensitivity (nominal (rated)
signal range between torque = zero and
nominal (rated) torque)
Frequency output 10 kHz kHz 5
Voltage output V 10
Rated output tolerance (deviation of the
actual output quantity at M
nom
from the
nominal (rated) signal range)
% ≤±0.1
nominal (rated) output signal
Frequency output (RS422, 5V symmetrical)
with positive nominal (rated) torque
with negative nominal (rated) torque
kHz
kHz
15
5
Voltage output
with positive nominal (rated) torque
with negative nominal (rated) torque
V
V
+10
-10
Output signal at torque = zero
Frequency output
Voltage output
kHz
V
10
0
