Operation
Display/TouchScreen
60 A03470_07_E00_00 HBM: public DMP41
6.4.3 Display in setting mode (Settings)
The screens shown on the PC and the DMP41 may differ (no direct screen
correlation).
4
56
7
8
AB
Function keys bar
2
1
3
C
Measurement channel settings (Channel)
Bridge excitation voltage and measuring range
Filter
Scaling
Device settings (Device)
Password
Device name
Display brightness
Interface settings (Interfaces)
Ethernet interface
RS232 interface
A
1
2
3
B
4
5
6
C
7
8
