Operation
Display/TouchScreen
DMP41 A03470_07_E00_00 HBM: public 59
Signal type in the display
You can display the absolute, gross and net signals in sequence for each
measuring point.
0 0,5 1.0 1.5
Absolute
Gross
Net
Zero value Tare value
0.75 (relative to tare value 0.25 mV/V)
Measured value
mV/V
User-defined scaling
Zero value = 0.5 mV/V
Tare value = 0.25 mV/V
The following values appear in the display for this example:
Absolute 1.5 mV/V
Gross 1.0 mV/V
Net 0.75 mV/V
