5.1 WE2111-ZCC contact assignment
Function Imprint
Current output (+), 600Ω max. IOUT+
Current output (-), 600Ω max. IOUT-
Voltage output (+), 2000Ω min. VOUT+
Voltage output (-), 2000Ω min. VOUT-
Input/output 1 I/O1
Input/output 2 I/O2
Common supply +U
b
COM+
Common supply -U
b
(ground) COM-
Cable shield SHIELD
5.2 WE2111-ZS contact assignment
Function Imprint
Common supply +U
b
COM+
Common supply -U
b
(ground) COM-
Input/output 1 I/O1
Input/output 2 I/O2
Input/output 3 I/O3
Input/output 4 I/O4
Input/output 5 I/O5
Input/output 6 I/O6
Input/output 7 I/O7
Input/output 8 I/O8
Cable shield SHIELD
