1. Room/Floor Temp - Indicates the current temperature sensor mode.
2. Day Indicator - Displays the current day.
3. Frost Icon - Displayed when the thermostat is in frost protection mode.
4. Flame Icon - Displayed when the thermostat is calling for heat, the ame icon
will ash when the optimum start function is in operation.
5. Floor Temp Limit Icon - Displayed when the oor sensor probe has reached the
temperature limit set on feature 07.
6. Set - Indicates when changes are being made to programs or temperature set
points.
7. Holiday Indicator - Displayed when the thermostat is in holiday mode.
8. Current Temp - Indicates the current sensor temperature.
9. Program Cycle Indicator - Displayed during programming only to show which
period is being altered.
10. Keypad Lock Indicator - Displayed when the keypad is locked.
11. Units of Temperature - Degrees Celsius or Fahrenheit.
12. Clock - Digital clock display in 24h format.
13. T emperature Hold - When a Temp Hold is active, HOLD FOR and the remaining
time period is displayed.
LCD Display
Model: Slimline-E V3
10
