80-23024 Issue 3r1 HEBER
3 ASSEMBLY PREP
You will first need to prepare a DE10-nano FPGA evaluation board –
Please first check that the micro SD Card has been removed from the DE10-nano board – this is
really important as you could snap the card if you try to install into the enclosure without first
removing it.
3.1 Recommended tools
You should only require a Philips Number 1 screwdriver to install and setup your Multisystem.
If you have printed your own enclosure, you may also require snips. Tweezers or small pliers will
also assist with assembly. Retro snack is not essential, but is very highly recommended.
